Daikin FTXS35D3VMW [2/24] 2 technical specifications
![Daikin FTXS35D3VMW [2/24] 2 technical specifications](/views2/1780135/page2/bg2.png)
3
1
2
• Split Sky Air • Indoor Units 2
• Indoor Units • R-410A • FTKS-D3VMW_D2V1W
2 Specifications
2-1 FOR INDOOR UNITS ONLY
FTKS20D3VMW FTKS25D3VMW FTKS35D 3VMW FTKS50D2V1W
Nominal Input Cooling kW 0.035 0.035 0.040 0.048
2-2 TECHNICAL SPECIFICATIONS
FTKS20D3VMW FTKS25D3VMW FTKS35D 3VMW FTKS50D2V1W
Casing Colour White
Dimensions Packing Height mm 340 340 340 340
Width mm 855 855 855 855
Depth mm 265 265 265 265
Unit Height mm 283 283 283 283
Width mm 800 800 800 800
Depth mm 195 195 195 195
Weight Unit kg 9.0 9.0 9.0 9.0
Packed Unit kg 12.0 12.0 12.0 12.0
Heat
Exchanger
Dimensions Length mm 610 610 610 610
Nr of Rows 2 2 2 2
Fin Pitch mm 1.40 1.40 1.40 1.40
Nr of Stages 12 12 12 14
Tube type Hi-XA (7)
Fin Type ML fin (Multi louver)
Fan Type Cross flow fan
Air Flow Rate Cooling High m³/min 8.7 8.7 8.9 11.4
Medium m³/min 6.7 6.7 6.9 9.3
Low m³/min 4.7 4.7 4.8 7.1
Silent
Operation
m³/min 3.9 3.9 4.0 6.2
Fan Motor Quantity 1 1 1 1
Model KFD-280-40-8B
Number of steps 5 steps, silent and auto
Motor Speed
(cooling)
High rpm 1250 1250 1270 1580
Medium rpm 1030 1030 1050 1330
Low rpm 810 810 830 1090
Silent
Operation
rpm 710 710 730 980
Fan Motor Output
(high)
W 40 40 40 40
Cooling Sound Power High dBA 56.0 56.0 57.0 62.0
Sound
Pressure
High dBA 38.0 38.0 39.0 46.0
Medium dBA 41.0
Low dBA 25.0 25.0 26.0 35.0
Silent
Operation
dBA 22.0 22.0 23.0 32.0
Refrigerant Type R-410A
Piping
connections
Liquid (OD) Diameter
(OD)
mm 6.35 6.4 6.4 6.4
Gas Diameter
(OD)
mm 9.5 9.5 9.5 12.7
Drain Diameter
(OD)
mm 18 18 18 18
Heat Insulation Both liquid and gas pipes
Air Filter Removable/washable/Mildew proof
Air direction control Left, right, up and downwards
Temperature control Microcomputer control
