Si04-803 Specifications
Specifications 11
50Hz 220-230-240V / 60Hz 220-230V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTKS25EVMA FTKS35EVMA
Outdoor Units RKS25EBVMA RKS35EBVMA
Capacity
Rated (Min.~Max.)
kW 2.5 (1.2~3.0) 3.5 (1.2~3.8)
Btu/h 8,500 (4,100~10,200) 11,900 (4,100~12,950)
kcal/h 2,150 (1,030~2,580) 3,010 (1,030~3,260)
Moisture Removal L/h 1.2 1.9
Running Current (Rated) A 3.5-3.3-3.2 / 3.5-3.3 4.9-4.7-4.5 / 4.9-4.7
Power Consumption (Rated) W 600 (300~800) 1,020 (300~1,200)
Power Factor % 77.9-79.1-78.1 / 77.9-79.1 94.6-94.4-94.4 / 94.6-94.4
COP (Rated) W/W 4.17 (4.00~3.75) 3.43 (4.00~3.17)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant
g/m 20 20
Indoor Units FTKS25EVMA FTKS35EVMA
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 8.7 (307) 8.9 (314)
M 6.7 (237) 6.9 (244)
L 4.7 (166) 4.8 (169)
SL 3.9 (138) 4.0 (141)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.17-0.16-0.15 / 0.17-0.16 0.19-0.18-0.17 / 0.19-0.18
Power Consumption (Rated) W 35-35-35 / 35-35 40-40-40 / 40-40
Power Factor % 93.6-95.1-97.2 / 93.6-95.1 95.7-96.6-98.0 / 95.7-96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/M/L/SL dBA 37/31/25/22 38/32/26/23
Outdoor Units RKS25EBVMA RKS35EBVMA
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD 1YC23NXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 1.0 1.0
Airflow Rate
m³/min
(cfm)
H 33.5 (1,183) 33.5 (1,183)
L 23.4 (826) 23.4 (826)
Fan
Type Propeller Propeller
Motor Output W 50 50
Running Current (Rated) A 3.33-3.14-3.05 / 3.33-3.14 4.71-4.52-4.33 / 4.71-4.52
Power Consumption (Rated) W 565-565-565 / 565-565 980-980-980 / 980-980
Power Factor % 77.1-78.2-77.2 / 77.1-78.2 94.6-94.3-94.3 / 94.6-94.3
Starting Current A 3.5 4.9
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 589×882×363 589×882×363
Weight kg 34 34
Gross Weight kg 40 40
Operation
Sound
H/L dBA 46/43 47/44
Sound Power (H) dBA 61 62
Drawing No. 3D058977 3D058978
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
