Si04-803 Outdoor Unit
Removal Procedure 189
Warning
If refrigerant gas leaks
during the job,
ventilate the room.
(Bear in mind that if
the refrigerant gas is
exposed to open
flames, noxious gas
may be generated.)
Provide a protective sheet or
a steel plate so that the
brazing flame cannot
influence peripheries.
Be careful so as not to break
the pipes by pressing it
excessively by pliers when
withdrawing it.
Step
Procedure Points
(R7250)
