Si04-803 Specifications
Specifications 13
50Hz 220-230-240V / 60Hz 220-230V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTKD25DVMA FTKD35DVMA
Outdoor Units RKD25DAVMA RKD35DAVMA
Capacity
Rated (Min.~Max.)
kW 2.5 (1.3~3.0) 3.5 (1.4~3.8)
Btu/h 8,500 (4,400~10,200) 11,900 (4,750~12,950)
kcal/h 2,150 (1,100~2,580) 3,010 (1,200~3,260)
Moisture Removal L/h 1.2 1.9
Running Current (Rated) A 4.2-4.0-3.8 / 4.2-4.0 5.4-5.2-5.0 / 5.4-5.2
Power Consumption
Rated (Min.~Max.)
W 725 (310~1,030) 1,130 (305~1,370)
Power Factor % 78.5-78.8-79.5 / 78.5-78.8 95.1-94.5-94.2 / 95.1-94.5
COP (Rated) W/W 3.45 (4.19~2.91) 3.10 (4.59~2.77)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTKD25DVMA FTKD35DVMA
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 8.9 (314) 9.0 (318)
M 7.3 (258) 7.4 (261)
L 5.6 (198) 5.7 (201)
SL 4.8 (169) 4.9 (173)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.17-0.16-0.15 / 0.19-0.18 0.19-0.18-0.17 / 0.21-0.20
Power Consumption (Rated) W 35-35-35 / 40-40 40-40-40 / 45-45
Power Factor % 93.6-95.1-97.2 / 95.7-96.6 95.7-96.6-98.0 / 97.4-97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (W×D×H) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 37 / 28 / 25 38 / 29 / 26
Outdoor Unit RKD25DAVMA RKD35DAVMA
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23RXD 1YC23RXD
Motor Output W 600 600
Refrigerant
Oil
Type SE56P SE56P
Charge L 0.375 0.375
Refrigerant
Type R-22 R-22
Charge kg 0.9 1.2
Airflow Rate m³/min (cfm)
H 35.4 (1,250) 30.9 (1,091)
L 25.0 (883) 21.5 (759)
Fan
Type Propeller Propeller
Motor Output W 50 50
Running Current (Rated) A 4.03-3.84-3.65 / 4.01-3.82 5.21-5.02-4.83 / 5.19-5.0
Power Consumption (Rated) W 690-690-690 / 685-685 1,090-1,090-1,090 / 1,085-1,085
Power Factor % 77.8-78.1-78.8 / 77.6-78.0 95.1-94.4-94.0 / 95.0-94.3
Starting Current A 4.2 5.2
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (W×D×H) mm 589×882×363 589×882×363
Weight kg 32 34
Gross Weight kg 37 40
Operation
Sound
H/L dBA 46 / 43 47 / 44
Drawing No. 3D058991 3D058992
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
