FT(Y)S60B
unit (mm)
3D040080
Left
Rear
Right
The mark (Y) shows piping direction
Home leave lamp
Signal receiver
Bottom
Flaps
Front grille fixing screws
(Inside)
Timer lamp
Operation lamp
Signal transmitter
Infrared remote control
Horizontal blade
(Automatic)
Blade angle
Vertical blade (Automatic)
Air flow (indoor) required space (for
performance and maintenance)
(space for
maintenance)
(including installation
plate)
Name plate
Terminal block
with earth
terminal
(space for
performance)
(space for
maintenance)
Liquid pipe J A Cut (The length of pipe
outside the unit: about 390)
Gas pipe J B Cut (The
length of pipe outside the
unit: about 340)
Drain hose (connecting part I.D.
J 14.0, O.D. J 18.0)
(The hose length on the
outside of the unit is
approx. 440)
Wall hole for embedded piping
J 80 hole
Wall hole J 80 hole
Standard locations of wall holes
Cooling
Indoor unit ON/OFF
switch
Dry
Intelligent eye sensor
Room temp. thermistor
FTYS---: (ARC433A23)
FTS---: (ARC433A24)
Rear
Heating
(FTX -- only)
Required space
A
FTX(K)S60•71-- 6.4
B
FTX(K)S60--
12.7
FTX(K)S71--
•
Wall Mounted Unit • R-410A • FT(Y)S20,25,35,50,60BVMB
3
Dimensional drawings
