3
Capacity tables
ARK + ATK25B
Cooling 230V [50Hz]
AFR 7.8
BF 0.30
Indoor Outdoor temperature (°C)
EWB EDB 20 25 30 32 35 40
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20 2.33 1.55 0.67 2.25 1.49 0.74 2.17 1.44 0.82 2.14 1.42 0.83 2.08 1.38 0.85 2.00 1.32 0.92
16.0 22 2.51 1.67 0.68 2.43 1.61 0.76 2.35 1.56 0.83 2.31 1.53 0.85 2.25 1.49 0.87 2.16 1.43 0.94
18.0 25 2.70 1.79 0.69 2.61 1.73 0.77 2.52 1.67 0.85 2.48 1.65 0.86 2.42 1.60 0.88 2.32 1.54 0.95
19.0 27 2.80 1.85 0.70 2.70 1.79 0.78 2.61 1.73 0.86 2.57 1.70 0.87 2.50 1.66 0.89 2.40 1.59 0.96
22.0 30 3.09 2.05 0.72 2.99 1.98 0.80 2.88 1.91 0.88 2.84 1.88 0.90 2.76 1.83 0.92 2.65 1.76 0.99
24.0 32 3.28 2.18 0.73 3.18 2.11 0.81 3.07 2.04 0.90 3.02 2.00 0.91 2.94 1.95 0.93 2.81 1.87 1.01
3D040457
ARK + ATK35B
Cooling 230V [50Hz]
AFR 8
BF 0.17
Indoor Outdoor temperature (°C)
EWB EDB 20 25 30 32 35 40
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20 3.21 2.19 0.77 3.06 2.12 0.87 2.91 2.05 0.96 2.85 2.02 1.00 2.76 1.98 1.06 2.61 1.91 1.15
16.0 22 3.37 2.22 0.80 3.22 2.15 0.89 3.07 2.08 0.99 3.01 2.06 1.02 2.92 2.01 1.08 2.77 1.94 1.18
18.0 25 3.52 2.26 0.82 3.37 2.19 0.92 3.22 2.12 1.01 3.16 2.09 1.05 3.07 2.05 1.11 2.92 1.98 1.20
19.0 27 3.60 2.27 0.84 3.45 2.20 0.93 3.30 2.13 1.03 3.24 2.11 1.06 3.15 2.06 1.12 3.00 1.99 1.22
22.0 30 3.83 2.33 0.87 3.68 2.26 0.97 3.53 2.19 1.06 3.47 2.16 1.10 3.38 2.12 1.16 3.23 2.05 1.25
24.0 32 3.99 2.36 0.90 3.84 2.29 1.00 3.69 2.22 1.09 3.63 2.19 1.13 3.54 2.15 1.19 3.39 2.08 1.28
3D040458
SYMBOLS
AFR : Air flow rate (m
3
/min)
BF : Bypass factor
EWB : Entering wet bulb temp. (°CWB)
EDB : Entering dry bulb temp. (°CDB)
TC : Total cooling capacity (kW)
SHC : Sensible heating capacity (kW)
PI : Power input (kW)
Caution:
TC and SHC are shown by kW
NOTES
1 Ratings shown are net capacities which include a deduction for
indoor fan motor heat
2 shows nominal (rated) capacities and power input.
3 TC, PI and SHC must be calculated by interpolation using the figures
in the above tables. (Figures out of the tables should not be used for
calculation.)
4 SHC is based on each EWB and EDB
SHC* = SHC correction for other dry bulb
= 0.02*AFR (m
3
/min.)*(1-BF)*(DB*-EDB)
Add SHC* to SHC.
5 Capacities are based on the following conditions:
Corresponding refrigerant piping length: 7.5 m
Level difference: 0 m
6 Air flow rate (AFR) and Bypass factor (BF) are taburated above.
•
Pair application • R-410A • ARK25,35BVMB
1
3
6
• Split - Sky Air • Outdoor Units
