Daikin FCQH140D8VEB [5/25] Specifications
![Daikin FCQH100D8VEB [5/25] Specifications](/views2/1781308/page5/bg5.png)
• Split Sky Air • Indoor Units
3
• Indoor Units • Cooling Only/Heat Pump • FCQH-D8VEB
2 Specifications
2-1 Technical Specifications FCQH71D8VEB FCQH100D8VEB FCQH125D8VEB FCQH140D8VEB
Casing Material Galvanised steel plate
Dimensions Packing Height mm 262 304 304 304
Width mm 882
Depth mm 882
Unit Height mm 246 288 288 288
Width mm 840
Depth mm 840
Weight Unit kg 23 25 25 25
Packed Unit kg 28 30 30 30
Heat Exchanger Dimensions Length mm inside: 2,096, outside: 2,152
Nr of Rows 2
Fin Pitch mm 1.2
Nr of Passes 5 111111
Face Area m² 0.446 0.535 0.535 0.535
Nr of Stages 10 12 12 12
Empty tubeplate hole
Quantity 0
Fin Type Cross fin coil (Multi louver fins and Hi-XSS tubes)
Fan Type Turbo fan
Quantity 1
Air Flow Rate Cooling High m³/min 21.9 34.2 34.2 34.2
Low m³/min 12.1 17.6 21.2 23.8
Heating High m³/min 21.9 34.2 34.2 34.2
Low m³/min 12.1 17.6 21.3 23.9
Fan Motor Model QTS48C15M
Number of steps 3
Output (high) W 120
Cooling Sound Power High dBA 54 62 62 62
Sound Pressure High dBA 36 45 45 45
LowdBA28323638
Heating Sound Pressure High dBA 36 45 45 45
LowdBA28323638
Piping connections Sound Absorbing Insulation Foamed polyurethane
Refrigerant Type R-410A
Piping connections Liquid (OD) Type Flare connection
Diameter (OD) mm 9.52
Gas Type Flare connection
Diameter (OD) mm 15.9
Drain Diameter (OD) mm VP25 (I.D. 25/O.D. 32)
Heat Insulation Foamed polystyrene/foamed polyethylene
Decoration Panel Model BYCQ140CGW1
Colour Pure White(RAL 9010)
Dimensions H mm 130
Wmm 950
Dmm 950
Weight kg 5.5
Decoration Panel 2/3 Model BYCQ140CW1W/BYCQ140CW1
Colour Pure White(RAL 9010)
Dimensions H mm 50
Wmm 950
Dmm 950
Weight kg 5.5
Air Filter Resin net with mold resistance
