Page 8/13
9. Check personal information of input
Personal information input is confirmed.
Command format D?
Reaction equipment transmits input data
The item described to next table is transmitted by CSV.
Items
*Preset tare D0XX.X (XX.X 4 bytes fixed length)
Gender D1X (X Female=2, Male=1)
Body type D2X (X Standard=0, Athletic=2)
Height D3XXX.X (XXX.X 5 bytes fixed length)
Age D4XX (XX 2 bytes fixed length)
*Result number
D5XXXXXXXXXX (XXXXX 10 – 16bytes variable length)
*target fat %
D6XX (XX 2 bytes fixed length)
*: Not essential information for measurement
Transmission example D?
ACK (When all items are set)
D01.5,D11,D20,D3175.4,D430,D50000012345,D620
ACK (When all items are not set)
D000.0,D1!,D2!,D3!,D4!,D5!,D6!
NAK (unacceptable) !
