Truvox Hydromist® 35 [3/4] Hm35 sheet 3

Truvox Hydromist® 35 [3/4] Hm35 sheet 3
Part Number:
Sheet no.
DESCRIPTION OF CHANGE
ECN #
Format Change -
Tacony CFC
Hydromist 35
HM35
Dat
pr
-A
-19
42
e:
Reference Parts List Issue:
13
Drawing
Number: 09-1108-
)
A
Series
(
0000
3 / 3
Drawing Issue:
C
Modified By:
J WYLES
Ref. No. Part No. Part Description Qty
HM35 Sheet 3
21 X8241
NUT HEX HEAD 10-24
2
2 X9169
FLANGE NUT HEX HEAD 10-32 StSt
33 7BH004
10-32 x3/8 PHIL PAN StSt
1
4 X9100
GROMMET 1/2"
1
5 PC45
1/8" CLOSE NIPPLE
26 X9174
LOCKING PLUG 3/4" UNVENTED
17
PC66
FITTING 1/8" NPTM x 1/4 HOSE BARB
28 X9001
BRUSH BEARING
1
9 X9017
BRUSH AXLE
1
10 X9019
BRUSH BEARING SHIELD
211 X9018
BRUSH BEARING SPACER NYLON
212 X9030
BRUSH FOOT PEDAL
1
13 X9015
BRUSH HOUSING
1
14 X9107
BRUSH LIFTING BRACKET
1
15 X9026
BRUSH LIFT PEDAL
2
16 X9027
BRUSH LIFT PEDAL SPACER
1
17 X9020
BRUSH THREAD GUARD
1
18 X9070
BRUSHROLL
1
19 9DL003
CLAMP 1/4 WORM GEAR StSt
1
20 X9015B
COVERPLATE BRUSH MOTOR BELT
121 X9015A
BRUSH MOTOR COVERPLATE
1
22 X9004
BRUSH DRIVE BELT
1
23 X9117
DRIVE PULLEY 24 TEETH
1
24 X9116
DRIVE PULLEY 12 TOOTH (WITH 2 OFF 8-32 SET SCREWS)
4
25 X9114
E RING 1/4"
1
26 7AK003
ELBOW UNION 1/8" NPT
1
27 X9282
EMI FILTER BRUSH MOTOR
1
28 X9150
GASKET BELT COVER
1
29 X9126
GASKET BRUSH MOTOR COVER
130 71817A
BRAIDED HOSE 1/4" (16" LONG)
231 X9139B
HM35 MINATURE NOZZLE
1
32 X9119
MOTOR 220VDC 1/4HP 3"
4
33 7BF008
NUT 10-32 KEPS StSt
1
34 X8830
NYLON LOCK NUT 10-32 StSt
2
35 X8237
NUT, 1/4-20, LOCK NYLON INSERT ZINC PLATED
2
36 X8293
WASHER NYLON .50"I/D X .75"OD X .130"THK BLACK
1
37 X1193
RECTIFIER 1000V 35 AMP
1
38 X9122
SAFETY WALK TAPE 1" WIDE
1
39 7CU001
SCREW PHILLIPS PAN HEAD 10-24 X 1 StSt
2
40 71651A
SCREW 10-32 X 1/2 PHIL PAN MS StSt
1
41 9BR005
SCREW 10-32 X3/4" PHIL StSt
1042 X9118
SCREW FLAT HEAD 10-32 X 5/8 StSt
243 9CU003
SCREW 1/4-20 X 1" PHIL StSt
2
44 X9099
MOTOR SPACER
1
45 X9021
SPRAY MANIFOLD
146 X9128
SUPERIOR EDGE LABEL
1
47 9CM003
WASHER #10 FLAT StSt
2
48
7CM004
StS
HD
FLAT
USS
3/8
t
Washer,
2
49 9CM007
WASHER 1/2 USS FLAT 18-8 StSt
650 92241A
WASHER 1/4" ID FLAT .059" THICK NYLON
1
51 X9438
BRUSH ASSEMBLY HM35
2
52 X1745
NOZZLE BODY
