SA Indoor Unit - FFQ, FCQ, FDBQ, FBQ, FHQ Series SiBE121021_C
256 Operation Manual
38 English
5
Note
(* Maximum temperature – Minimum temperature ≥ 6°C)
Menu Manipulation
• To make limit operation settings, press
buttons to move the highlighted
item and press buttons to input the
desired set time.
• Press buttons to move the
highlighted item and press buttons
to set the operation to .
• To change the maximum and minimum
temperatures, press the Menu/Enter
button so that the temperatures will be
ready to be changed.
• Press buttons to select the desired
temperature to be changed.
• Pressing Menu/Enter button enters the
set temperature change.
• The difference between the maximum and minimum
temperatures cannot be set to less than 6°C.
• Press buttons to change the set
temperature.
The set temperature will increase by 1°C
when the button is pressed and
decrease by 1°C when the button is
pressed.
