SiBE121021_C Outdoor Unit - 50~75 Class
Removal Procedure 393
3
Untie the fixing strings
to open the sound
blanket (outer) and pull
it out.
4
Open the sound blanket
(inner) and pull it out.
Step
Procedure Points
Sound
blanket
(outer)
(R5583)
(R5584)
Sound blanket
(inner)
