Outdoor Unit - 80/90 Class SiBE121021_C
412 Removal Procedure
2
Slide the partition plate
(2) to the left and
remove it.
3
Remove the 5 screws
on the wire fixing plate
(upper).
Step
Procedure Points
(R11211)
(R11210)
Wire fixing
plate (upper)
