Truvox Multiwash II 440/PUMP [5/17] Please refer to the back of the manual for pictorial instructions

Truvox Multiwash II 240/PUMP [5/17] Please refer to the back of the manual for pictorial instructions

4 10-18

The following simple checks may be performed by the operator. If the machine is still not working, please contact your local Service Agent:

* If the fuse blows several times, the machine should be checked by an authorised Service Agent.

PLEASE REFER TO THE BACK OF THE MANUAL FOR PICTORIAL INSTRUCTIONS

Trouble

Reason

Remedy

Machine fails to start – no power

 Transport working lever is in bottom position

(see picture 3 on page 15)

 Change to operating position (see pictorial guide)

 Motor overload protector has tripped

 Wait for 1 hour to allow the motor temperature

to reach room temperature. Then try again.

 Transport wheels not raising off the ground

when handle lowered

 Check for debris and clean machine.

 Lack of voltage / electrical supply

 Check fuse *, power cord, plug and socket outlet

Machine fails to pick up water from the

floor

 Incorrectly fitted / damaged recovery tank

 Refit or replace recovery tank

 Worn brushes

 Check brush pressure, if needed replace brushes.

 Drum not rotating

 See below

Drum not rotating

 Debris around drum or base of machine

 Clean drum and base of the machine.

Drum is rotating, but brushes are not

 Debris around brushes

 Clean or replace brushes

Machine fails to spray solution onto the

floor (MW240/Pump, MW340/Pump &

MW440/Pump only)

 Faulty pump

 Can you hear the pump operating? If yes, see

below.

If no:

Check pull cable is fitted correctly, see below.

 Incorrectly fitted / damaged pull cable

 Refit / replace pull cable - this should be on the

right hand side of the machine from the operator's

position.

 No solution in solution tank

 Fill solution tank

 Blocked jet

 Clean jet

 Blocked inline filter

 Clean inline filter

 Blocked filter or faulty valve in solution tank

 Clean / replace filter or valve

Machine only sprays when handle in

upright position

 Lower handle bolts are loose

 Tighten lower handle bolts

Machine fails to pour solution onto the

floor (MW240 & MW340 only)

 Incorrectly fitted / damaged pull cable

 Refit / replace pull cable - this should be on the

right hand side of the machine from the operator's

position.

 Dirty filter in clean water tank

 Empty solution tank and fill up with clean water

 Blocked holes in outlet channel

 Clean holes in outlet channel

 Replace solution tank

Motor makes a humming noise but does

not turn

 Debris around drum and base of the machine

 Clean drum and base of machine
