SPECIFICATIONS
EUW*40MX EUW*60MX EUW*80MX EUW*100MX EUW*120MX
120 190 249 290 380
149 237 313 362 474
30.0 48.6 66.1 74 97.2
35.1 57.2 75.5 87.3 114.0
100-74-48-12(start up) 100-74-48-36-12(start up)
100-88-76-63-50-38-
25-12(start up)
R-134a R-134a R-134a R-134a R-134a
semi-hermetic single screw
1/1 1/1 1/1 1/1 2/2
1,014 x 2,672 x 898 2,000 x 2,672 x 898
990 1,320 1,640 1,680 2,640
1,020 1,370 1,710 1,760 2,740
90 96 96 98 99
3~/400V/50Hz
3~/230V/50Hz
Nominal capacity cooling kW
heating kW
Nominal input cooling kW
heating kW
Capacity steps %
Refrigerant circuit type
Compressor type
No. of circuits/compressors
Dimensions mm
Machine weight kg
Operation weight kg
Sound power level dB(A)
Power supply Y1
T1
EUW*140MX EUW*160MX EUW*180MX EUW*200MX
439 498 539 580
626 675 724
115 132 140 148
133.0 151 163 175
100-88-76-63-50-38-25-12(start up)
100-87-74-68-50-37-24-18-12(start up)
R-134a R-134a R-134a R-134a
semi hermetic single screw
2/2 2/2 2/2 2/2
2,000 x 2,672 x 898
2,960 3,280 3,320 3,360
3,080 3,420 3,470 3,520
99 99 100 101
3~/400V/50Hz
3~/230V/50Hz
Nominal capacity cooling kW
heating kW
Nominal input cooling kW
heating kW
Capacity steps %
Refrigerant circuit type
Compressor type
No. of circuits/compressors
Dimensions mm
Machine weight kg
Operation weight kg
Sound power level dB(A)
Power supply Y1
T1
option option description model-type unit size
availability
number PED d s 40 50 60 80 100 120 140 160 180 200
Completely combinable options
op01 liquid line solenoid valve o std std o o o o o o o o o o fact. mounted
op03 dual pressure relief valve on the condenser o std std o o o o o o o o o o fact. mounted
op12 suction stop valve (only Y1-model) o std std o o o o o o o o o o fact. mounted
op52 main isolator switch o o o o o o o o o o o o o fact. mounted
op57 a-meter, V-meter o o o o o o o o o o o o o fact. mounted
OPLN low noise operation o o o o o o o o o o o o o fact. mounted
o available
std standard
OPTIONS
00225•New products•01-12 09-11-2001 11:18 Pagina 51
