1 Solar - flow or connection for addition-
al heat source(1" IG)
2 Cold water flow (1" AG)
3 Hot water flow (1" AG)
4 Heating flow (1" AG)*
5 Heating return (1" AG)*
6 Circulation pump
7a Recommended accessories:
non-return valves (2 pcs.)
9 Storage tank (double walled jacket made
of polypropylene with PUR hard foam heat
insulation)
10 Filling and drainage connection or
Solar - return flow connection
11 Mount for solar controller or handle
12 Heat exchanger (stainless steel) for drink-
ing water heating
13 Heat exchanger (stainless steel) for stor-
age tank charging or heating support
14 Heat exchanger (stainless steel) for pres-
surised solar storage tank charging
15 Connection for optional electrical Backup-
Heater EKBUxx (R 1½" IG)
16 Solar inflow layering pipe
17 Fill level indicator (tank water)
18 Optional: Electrical Backup-Heater
(EKBUxx)
19 Submersible sensor sleeve for storage
tank temperature sensor t
DHW1
and t
DHW2
20 Unpressurised storage tank water
21 Solar zone
22 Hot water zone
23 Safety overflow connection
24 Mount for handle
25 Type plate
26 Protective cover
27 Solar - return
28 Solar - feed (3/4" IG + 1" AG)
Daikin Altherma EHS(X/H) B
(only Typ … Biv)
29 Solar - return (3/4" IG + 1" AG)
Daikin Altherma EHS(X/H) B
(only Typ … Biv)
30 Panel heat exchanger
31 Connection coolant fluid line
Daikin Altherma
EHS(X/H)…04P30B/08PxxB:
Cu Ø 6,4 mm (1/4"),
Daikin Altherma EHS(X/H)…16P50B:
Cu Ø 9.5 mm (3/8")
32 Connection to coolant gas line
Cu Ø 15,9 mm (5/8")
3UVB1
3-way diverter valve
(internal heat generator circuit)
3UV DHW
3 way diverter valve (hot water/heating)
DS Pressure sensor
FLS (t
R1
/ V1)
Return flow temperature and flow
sensor
t
DHW1
, t
DHW2
Storage tank temperature sensor
t
R2
Return flow temperature sensor
t
V1
Inflow temperature sensor
t
V, BH
Flow temperature sensor Backup-
Heater
RoCon B1
Operating section Daikin Altherma
EHS(X/H) control unit
EKSRPS4A
Optional: DaikinSolar regulation and
pump unit
Safety devices
Observe tightening torque!
AG Male thread
IG Female thread
* Ball cock (1" IG) is supplied with the equip-
ment
3 x Product description
Daikin Altherma EHS(X/H)
Daikin Altherma integrated solar unit
008.1441399_02 – 01/2021 – EN
Installation and operating instructions
15
Tab. 3-1 Legend from fig. 3-2 to fig. 3-5
