Installation and operating instructions
8
Daikin Altherma EHS(X/H)
Daikin Altherma integrated solar unit
008.1441399_02 – 01/2021 – EN
2 x Safety
2.4.5 Requirements for the heating and
storage water
Damage due to deposits and corrosion: observe
the current technological regulations to prevent
corrosion products and deposits.
Minimum requirements regarding the quality of
filling and top-up water:
● Water hardness (calcium and magnesium,
calculated as calcium carbonate): ≤ 3 mmol/l
● Conductivity: ≤ 1500 (ideal ≤ 100) μS/cm
● Chloride: ≤ 250 mg/l
● Sulphate: ≤ 250 mg/l
● pH value: 6,5 - 8,5
Measures for desalination, softening or
hardness stabilisation are necessary if the filling
and top-up water have a high total hardness
(>3 mmol/l – total of the calcium and magnesium
concentrations, calculated as calcium car-
bonate). We recommend the use of Fernox KSK
limescale and corrosion protector. For other
properties deviating from the minimum require-
ments, suitable conditioning measures are nec-
essary to maintain the required water quality.
Using filling water and top-up water which does
not meet the stated quality requirements can
cause a considerably reduced service life of the
equipment. The responsibility for this lies solely
with the operator.
2.4.6 Heating system and sanitary
connection
● Create a heating system according to the
safety requirements of EN 12828.
● The plumbing connection must comply with
the requirements of EN 12897. The require-
ments of the following must also be observed:
–EN 1717 – Protection against pollution of
potable water installations and general
requirements of devices to prevent pollu-
tion by backflow
–EN 61770 – Electric appliances connected
to the water mains – Avoidance of back-
siphonage and failure of hose-sets
–EN 806 – Specifications for installations
inside buildings conveying water for human
consumption
– and, in addition, the country-specific legis-
lation.
During operation of the indoor unit with an
auxiliary heat source, the storage tank temper-
ature may exceed 65
°C, above all when solar
energy is used.
● For this reason, some form of scalding
protection needs to be included when you
install the system (hot water mixing device,
e.g. VTA32).
If the indoor unit is connected to a heating
system with steel pipes, radiators or non-
diffusion-proof floor heating pipes, sludge and
chips can enter the hot water storage tank and
cause blockages, local overheating or corrosion
damage.
● To prevent possible damage, install a dirt filter
or sludge separator into the heating return
flow of the system (SAS 1 or SAS 2).
● The dirt filter must be cleaned at regular
intervals.
If an optional external heat generator is
connected, these minimum requirements
also apply to the filling and supple-
mentary water for this heating circuit.
The domestic water quality must comply
with the EU Guideline 98/83 EC and the
regionally-applicable regulations.
