4 x Start-up
Daikin Altherma EHS(X/H)
Daikin Solar tank with integrated interior heat pump unit
008.1420744 – 06/2015
Installation and maintenance manual
31
4Start-up
WARNING!
A Daikin Altherma EHS(X/H) that is installed or started
incorrectly may not operate properly and is dangerous
for the health and safety of individuals.
● The Daikin Altherma EHS(X/H) may only be
started up by authorised and trained heating
experts.
CAUTION!
A Daikin Altherma EHS(X/H) not put into operation
properly can lead to damage to property and the envi-
ronment.
● To prevent corrosion products and deposits,
observe the applicable regulations of technology
(VDI 2035, BDH/ZVSHK Techn
ical information
Deposit Formation"). Minimum requirements
regarding the quality of filling and supplementary
water:
– Water hardness (calcium and magnesium, cal-
culated as calcium carbonate): ≤ 3 mmo
l/l
– Conductivity: ≤ 270
0 μS/cm
– Chloride: ≤ 250 mg/l
– Sulphate: ≤ 250 mg/l
– pH value (heating water): 6.5 - 8.5.
● During system operation,
the water pressure at the
pressure gauge must be checked at regular
intervals. If necessary, readjust by refilling
4.1 Initial commissioning
After the Daikin Altherma EHS(X/H) was installed and connected
completely, it will need to be undergo a one-time adaptation to
the installation environment to be carried out by technical per-
sonnel (configuration).
After this configuration is complete, the
installation is ready for
operation and the operator can make additional custom configu-
rations on it.
The heating specialist must instruct the operator [on using the
machine], must prepare the commissioning report, and fill out the
operating manual.
The settings of the optional components such the room ther-
mostat or Daikin solar installation must be configured on the re-
spective components themselves.
4.1.1 Requirements
– The Daikin Altherma EHS(X/H) is fully connected.
– The coolant system is dehumidified and filled with the speci-
fied amount of coolant.
– The heating and hot water systems are filled and charged at
th
e right pressure (see chapter 6.5).
– The storage tank is filled up to the overflow (see chapter 6.4).
– Optional accessories have been mounted on and connected
up.
– The control valves of the
heating system are open.
4.1.2 Start-up
● Turn power supply to Daikin Altherma EHS(X/H) on.
After the start phase, the operating language selector is
displayed.
● Use the rotary
switch to select the desired language.
The operating language can be changed again at any
time.
● Confirm the changes with a brief push of the rotary switch.
The Daikin Altherma EHS(X/H) Basic Configuration is
loaded.
The message "Starting Up" is displayed.
The message "Initialization" is displayed.
The standard display for the current rotary switch setting
is displayed.
4.1.3 Set the commissioning parameters
To set the commissioning parameters, the heating expert must
be logged into the controller.
● Technician login
