1 x Safety
Daikin Altherma EHS(X/H)
Daikin Solar tank with integrated interior heat pump unit
008.1420744 – 06/2015
Installation and maintenance manual
5
1.3 Avoid danger
The Daikin Altherma EHS(X/H) is state-of-the-art and is built to
meet all recognised technical requirements. However, improper
use can lead to serious injuries or death, as well as causing ma-
terial damage.
To prevent such risks, install and operate Daik
in Altherma
EHS(X/H) only:
– as stipulated and in perfect condition,
– with an awareness of the safety and hazards involved.
This assumes knowledge and use of the contents of this manual,
the
relevant accident prevention regulations and the recognised
safety-related and occupational medical rules.
WARNING!
This unit is not intended for use by persons (including
ch
ildren) with impaired physical, sensory or mental
faculties or persons with insufficient experience and/or
expertise unless supervised by a person responsible
for ensuring their safety or are given instruction by this
person on how to use the unit.
1.4 Intended use
The Daikin Altherma EHS(X/H) may only be used for preparation
of warm water, as a room heating system, and depending on its
design, as a room cooling system.
The Daikin Altherma EHS(X/H) must be installed, connected and
o
perated only according to the indications in this manual.
Only use of a suitable external unit approved by Daikin is per-
mitted. The following combinations are permissible in this re-
spect:
Internal unit External unit
Heating and
cooling (X)
Heating only (H)
EHSX04P30A EHSH04P30A
ERLQ004CAV3
EHSXB04P30A EHSHB04P30A
EHSX08P30A EHSH08P30A
ERLQ006CAV3
ERLQ008CAV3
EHSXB08P3
0A EHSHB08P30A
EHSX08P5
0A EHSH08P50A
EHSXB08P50A EHSHB08P50A
EHSX16P50A EHSH16P50A ERLQ011CA(V3/W1)
ERLQ014CA(V3/W1)
ERLQ016CA(V3/W1)
EHSXB16P5
0A
EHSHB16P50
A
B -
Additional heat exchanger for the bivalent connection
* Not all the equipment mentioned here is offered in some countries because of
the various different country-specific connection conditions.
Tab. 1-1 Permissible combinations of Daikin Altherma EHS(X/H)
internal units and Daikin heat pump external units
Any other use outside the intended use is considered as im-
proper. The operator alone shall bear responsibility for any re-
sulting damage.
Use as intended also involves compliance with maintenance and
inspection conditions. Spare parts must at least satisfy the tech-
nical requirements defined by the ma
nufacturer. This is the case,
for example, with original spare parts.
1.5 Instructions for operating safety
1.5.1 Before working on the hydraulic system
● Work on the Daikin Altherma EHS(X/H) (such as setup,
servicing, connection and initial start-up) is only to be carried
out by persons who are authorised and who have success-
fully completed qualifying technical or vocational training and
who
have taken part in advanced training sessions recog-
nised by the appropriate responsible authorities for the
spe
cific activity. This, in particular, includes heating
specialists and climate control technicians who have
experience, as a result of their technical training and their
knowledge of the subject, of proper and appropriate instal-
lation and maintenance of heating, climate control and
cooling installations and heat pumps.
● Switch off the external
main switch before starting any work
on the Daikin Altherma EHS(X/H) and secure it against
unintentional switch-on.
● Sea
ls must not be damaged or removed.
● Make sure that the safety valves comply with the require-
ments of EN 12828 when connecting on the heating side, and
with the requ
irements of EN 12897 when connecting on the
domestic water side.
● Only origi
nal Daikin replacement parts may be used.
1.5.2 Electrical installation
● Electrical installation may be carried out only by electrical
engineers and in compliance with the valid electro-technical
guidelines as well as the regulations of the relevant energy
supply company (EVU).
● Comp
are the mains voltage (~230 V, 50 Hz or ~400 V, 50 Hz)
indicated on the type plate with the supply voltage before
connecting to the mains.
● Before be
ginning work on live parts, disconnect all of the
systems circuits from the power supply (switch off main
switch, disconnect fuse) and secure against unintentional
restart.
● Equ
ipment covers and service panels must be replaced as
soon as the work is completed.
