Besides guaranteeing the necessary air change, the RCU heat recuperative heaters can also recover heat
a high percentage of energy that is contained in foul air.
The heat gained from recycled air is transferred by means of a hygroscopic rotary recuperative heaters to
outer, colder air that gets pre-heated, thereby reducing the thermal shock as compared with inside tem-
perature. During summertime - when the outer air is characterized by high temperature and humidity - these
recuperative heaters similarly allow to pre-chill outside air if combined with an air-conditioning plant.
RCU-HE
ROTARY
RECUPERATIVE UNIT
HEAT RECOVERY UNITS
POSSIBLE INSTALLATION OPTIONS
Type 1 Type 2
=
expulsion air
=
inlet air
SERIES
CERTIFIED IN ACCORDANCE WITH
:
LOW TENSION DIRECTIVE 73/23/CEE
MACHINE DIRECTIVE 89/392/CEE
ELECTROMAGNETIC COMPATIBILITY
DIRECTIVE 89/336/CEE
