PECULIARITY
- Equipment operating at condensation conditions already at maximum heating capacity.
- Minimum efficiency about 102%
- Maximum efficiency about 108%.
- Very high average seasonal efficiency.
- Equipment operating at continuous modulating flame and continuous modulating air flow
conditions in order to immediately cope with the changing climatic needs of the treated
environment, thereby guaranteeing the highest overall energy efficiency.
- Combustion fumes temperature close to aspirated air flow temperature, thereby
guaranteeing the highest possible combustion efficiency.
- AISI 430 stainless steel combustion chamber.
- AISI 304 stainless steel, corrosion-resistant heat exchanger.
- Project covered by
international patent rights.
DUO-MO
totaL condensation AIR TREATMENT UNITS
WITH CONTINUOUS MODULATING FLAME
AND MODULATING AIR FLOW CONTROL
EFFICIENCY ~108%
SERIES
