Short name Meaning
1 Cold water distribution network
2 Hot water distribution network
3 Heating inflow
4 Heating return flow
5 Mixer circuit (optional)
6 Circulation (optional)
7 Check valve, return valve
7a Non return valves
8 Solar circuit
9 Gas pipe (refrigerant)
10 Fluid pipe (refrigerant)
3UV1 3-way switch valve (DHW)
3UV2 3-way switch valve (cooling)
EKBOyy Booster heater
BSK Burner blockage contact in EKSRPS4
BV Overflow valve
C Refrigerant compressor
CW Cold water
DHW Domestic hot water
E Expansion valve
EP3 Hot water module E-PAC LT (heating/cooling)
FLG FlowGuard - Solar regulating valve
FLS
FlowSensor - Solar flow and flow temperature
me
asurement
H
1,
H
2
... H
m
Heating circuits
HYW Low loss header
MAG Diaphragm expansion vessel
MIX 3-way-mixer with drive motor
MK1 Mixer group with high-efficiency pump
MK2
Mixer group with high-efficiency pump (PWM
controlled)
P
1
Central heating pump
P
HP
Heating circulation pump
P
Mi
Mixing circuit pump
P
S
Solar operating pump
P
Z
Circulation pump
PWT Panel heat exchanger (condenser)
RLB Return temperature limiter
EHS157068 Mixer circuit regulation
EKSRPS4 Solar regulating and pump unit
ERLQ Heat pump external unit LT
EKHBX Heat pump internal unit LT
RT Room thermostat
S#B Hot water storage tank EKHWP500B
SOL-M1 Solar communication module SOL-PAC2 LT
SK Solar panel field
SV Safety overpressure valve
t
AU
Outside temperature sensor
t
DHW
Storage tank temperature sensor (heat genera-
tor)
t
Mi
Mixer circuit flow temperature sensor
T
K
Solar collector temperature sensor
T
R
Solar return flow temperature sensor
T
S
Solar storage cylinder temp. sensor
T
V
Solar flow temperature sensor
V Fan (vaporiser)
VS Protection against scalding VTA32
Tab. 6-1 Short names in hydraulic drawings
Installation and maintenance manual
20
Daikin EKHWP300+500
Daikin High-performance hot water storage tank
008.1618744 – 08/2015
6 x Hydraulic connection
