Panasonic WV-NF284 [32/36] Specifications
![Panasonic WV-NF284 [32/36] Specifications](/views2/1788652/page32/bg20.png)
32
Specifications
General specification
Power source AC 24 V or DC 12 V, PoE (IEEE802.3af compliant)
Power consumption AC 24 V 60 Hz: 4.0 W, DC 12 V: 350 mA,
PoE: 4.0 W (Class 2 device)
Ambient temperature –10 °C to +50 °C
Ambient humidity 90 % or less
Monitor output
(only for adjustment) VBS: 1.0 V [P-P]/75 Ω, composite, ø3.5 mm mini jack
(monaural)
External I/O terminals ALARM IN, ALARM OUT, AUX OUT (x1 each)
Audio Captured by the built-in microphone
Dimensions ø122 mm x 136 mm (H)
Weight Approx. 640 g (including the camera mount bracket)
Camera
Image sensor 1/4 inch interline transfer CCD
Effective pixels 659 (H) x 494 (V)
Scanning area 3.59 mm (H) x 2.70 mm (V)
Scanning system Progressive
Resolution VGA: 640 x 480, QVGA: 320 x 240
Minimum illumination 1.5 lx (F1.4)
AGC Always ON (fixed)
Electronic shutter AUTO
Sensitivity up OFF, x2AUTO, x4AUTO, x8AUTO, x16AUTO
White balance AUTO/HOLD
Electronic Zoom 1x, 1.5x, 2x, 2.5x, 3x
VMD alarm ON/OFF, 4 areas available
Aperture control ALC (BLC ON/OFF)
ALC lens drive DC drive
Lens type 3.6x variable focal lens
Focal length (f) 2.8 mm - 10 mm
Aperture ratio 1 : 1.3 (WIDE), 1 : 3.1 (TELE)
Angular field of view Horizontal: 20.8 ° (TELE) – 73.5 ° (WIDE)
Vertical: 15.6 ° (TELE) – 54.4 ° (WIDE)
Adjusting angle Horizontal: 180 ° (clockwise), 140 ° (counterclockwise)
Vertical: ±75 °, Image tilt adjustment range: ±100 °
