Panasonic WV-NF284 [12/36] Major operating controls and their functions
![Panasonic WV-NF284 [12/36] Major operating controls and their functions](/views2/1788652/page12/bgc.png)
12
Major Operating Controls and Their Functions
INS
ER
T
A
D
J
U
S
T
L
O
C
K
D
O
C
O
M
E
V
E
R
N
q LEDs (Indicators)
(Link indicator, Access indicator,
SD memory card error indicator)
e Monitor out connector
(for adjustment)
r Image tilt adjustment
ring
t SD memory card slot
y Zoom ring
u Focus ring
w Indicators ON/OFF
switch
i Tilting table
!1 Dome cover lock
marker
!0 Panning table
o Panning table fixing
screw [LOCK]
MONITOR
OUT
GREEN : ACT
ORANGE : LINK
RED : SD CARD
ON OFF
LED
Explanatory label
DO
ME
C
O
V
E
R
!1 Dome cover lock
marker
!2 Microphone hole
!3 Inner dome
!4 Clear dome
<Inside the dome cover>
