Mounting screws
Only the fixing screws are provided to fix the
camera with the provided camera mount
bracket. It is necessary to procure screws or
bolts to mount the camera. Prepare them
according to the material and strength of the
area where the camera is to be installed. The
screws and bolts must be tightened with an
appropriate tightening torque according to
the material and strength of the installation
area.
Refresh interval
Image refresh interval may become slow
depending on the network environment, PC
performance, shooting subject, access num-
ber, etc.
Code labels
Retain these labels for future reference.
The codes on the label will be requested
when you contact the service station.
It is recommended to paste one of the labels
onto the CD-ROM case.
MPEG-4 Visual patent portfolio license
This product is licensed under the MPEG-4
Visual patent portfolio license for the person-
al and non-commercial use of a consumer for
(i) encoding video in compliance with the
MPEG-4 Visual Standard ("MPEG-4 Video")
and/or (ii) decoding MPEG-4 Video that was
encoded by a consumer engaged in a per-
sonal and non-commercial activity and/or
was obtained from a video provider licensed
by MPEG LA to provide MPEG-4 Video. No
license is granted or shall be implied for any
other use. Additional information including
that relating to promotional, internal and com-
mercial uses and licensing may be obtained
from MPEG LA, LLC.
See http://www.mpegla.com.
Distributing, copying, disassembling, reverse
compiling, reverse engineering, and also
exporting in violation of export laws of the
software provided with this product, is
expressively prohibited.
Be sure to install the safety wire.
