Panasonic WV-NF284 [5/36] Features
![Panasonic WV-NF284 [5/36] Features](/views2/1788652/page5/bg5.png)
5
Preface
The network camera WV-NF284 is designed to operate using a PC on a network (10BASE-
T/100BASE-TX).
By connecting to a network (LAN) or the Internet, images and audio from the camera can be
monitored on a PC via a network. *
1
Features
3.6x Varifocal lens provides variation of the angular field of view when installing the camera.
Progressive scan CCD (Charge-Coupled Device)
1/4 inch progressive scan CCD with VGA resolution (640 x 480 pixels) achieves high-fidelity
motion image scanning with high-resolution.
JPEG/MPEG-4 dual encode
MPEG-4 images can be monitored while recording JPEG images.
Power over Ethernet (IEEE802.3af compliant) function is featured
When connecting with a PoE (Power over Ethernet) device, power will be supplied by simply
connecting a LAN cable.
Audio monitoring is available using the built-in microphone.
Audio captured by the built-in microphone can be monitored using a PC via a network.
Wall mounting and ceiling mounting are available.
The camera can be installed on a ceiling or a wall directly using the provided camera mount
bracket. When using an optional ceiling mount bracket, embedded installation on a ceiling is
available.
Motion detection function *
2
This function detects a motion in a designated surveillance area and issue an alarm signal is
featured.
SD memory card slot
The FTP backup function and recording of each log on an optional SD memory card are avail-
able using the featured SD memory card slot.
*3
*
1
It is necessary to configure the network settings of the PC and its network environment to
monitor images and audio from the camera on the PC. It is also necessary that a web
browser is installed on the PC.
*
2
The motion detection function is not a dedicated function to prevent thefts, fires, etc. We
assume no responsibility whatsoever for any damages resulting from the use of the motion
detection function.
*
3
Performance with this camera has been checked by using Panasonic’s SD memory cards
(64 MB, 128 MB, 256 MB, 512 MB 1 GB and 2 GB). If another SD memory card is used,
this camera may not operate properly. (SD High Capacity (SDHC) card is not compatible
with this camera.)
