NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
WT-3
C
D
F
G
H
I
J
K
L
M
A
B
WT
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
NVH Troubleshooting Chart
BES00039
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: Applicable
Reference page
Refer to WT-4, "ROAD WHEEL"
—
—
—
—
—
—
NVH in MT, AT and CVT section.
NVH in FAX and FSU sections.
NVHinRAXandRSUsections.
Refer to TYRES in this chart.
Refer to ROAD WHEEL in this chart.
NVH in FAX section.
NVHinBRsection.
NVH in PS section.
Possible cause and SUSPECTED PARTS
Out-of-round
Imbalance
Incorrect tyre pressure
Uneven tyre wear
Deformation or damage
Non-uniformity
Incorrect tyre size
DIFFERENTIAL
FRONT AXLE AND FRONT SUSPENSION
REAR AXLE AND REAR SUSPENSION
TYRES
ROAD WHEEL
DRIVE SHAFT
BRAKE
STEERING
Symptom
TYRES
Noise ×××××× ××× ××××
Shake ××××× × ×× ××××
Vibration ××××××
Shimmy ××××××× ×× × ××
Judder ××××× × ×× × ××
Poor quality ride
or handling
××××× × ×× ×
ROAD WHEEL
Noise ×× × ×××× ×××
Shake ×× × ××× ×××
Shimmy, judder ×× × ××× ××
Poor quality ride
or handling
×× × ×××
