M-Audio Flying Calf [4/12] Features

Features

• High-quality, 24-bit stereo, A/D converter.

• Unbalanced analog inputs on independent left and right

1/4” jacks.

• S/PDIF digital output on an RCA connector.

• Transformer-coupled S/PDIF eliminates potential sys-

tem ground loops.

• Front panel input signal level displays for each channel.

• Jumper-selectable input levels.

• Compact desk-top size: 6.3” x 3.6” x 1.2”.

Panel Description

Front Panel

1. Sample Rate Indicator LED's: Show the current A/D sample

rate (either 44.1 kHz or 48 kHz). These LED's also double as

power indicators – one of the LED's is lit any time the unit’s

power is turned on.

2. Sample Rate Selector Button: Selects the current A/D sample

rate. When this button is out, the sample rate is set to 44.1

kHz. When the button is in, the sample rate is set to 48 kHz.

3. Input Level Displays: These LED display ladders accurately

depict the incoming signal levels at the A/D left and right

channels.

4. Power Button: When this button is in (and the power adapter

is properly plugged in), power is applied to the unit and one

of the Sample Rate Indicator LED's will be lit. When the but-

ton is out, the Flying Calf A/D is powered down.

Rear Panel

5. Power connector: For connection to the Calf’s power adapter.

The Flying Calf uses a 9 Volt DC, 500 milliamp (or greater),

center-pin positive supply.

6. Analog In (Left and Right): Analog audio inputs to the

Flying Calf’s A/D converter. These 1/4" jacks accept unbal-

anced line-level signals. Each jack provides a "tip/sleeve"

type of connection.
