6
FLYING
Calf A/D
S/PDIF
In
DIGITAL AUDIO
CARD
(Inside PC)
S/PDIF
Out
Analog In
Right
Analog In
Left
In 4
In 3
In 2
In 1
Mixer
Line Out
Left
Right
Typical Setup - Fig. 2
