CONTROLLING SPEED AND DIRECTION WITH THE TILLER

These motors are equipped with an extension twist tiller with a telescoping handle, which off ers a choice of fi ve forward and three

reverse speeds. The speed control may be operated in either direction, forward or reverse. Turn the tiller handle counterclockwise

from (OFF) to increase reverse speed and clockwise from (OFF) to increase forward speed. Thrust decreases as you approach

(OFF) from either direction.

OFF

REVE RSE

FORWARD

5 4 3 2 1

ADJUSTING THE DEPTH OF THE MOTOR

When setting the depth be sure the top of the motor is submerged at least

12” to avoid churning or agitation of surface water. The propeller must be

completely submerged.

1. Firmly grasp the composite shaft and hold it steady.

2. Loosen the steering tension knob and adjustable depth collar knob until

the shaft slides freely.

3. Raise or lower the motor to the desired depth.

4. Tighten adjustable depth collar knob to secure the motor in place.

CAUTION:

• Adjust the steering tension knob to provide enough tension to allow the

OR

• Tighten the knob to place the motor in a preset position to leave your
