118

C – VACUUMING DIRECTLY TO FILTER CHAMBER, WITHOUT A PAPER BAG, WITH OR WITHOUT

A “FIZELINA” FILTERING INSERT

Check if a paper bag is in the ﬁ lter chamber and remove it, if necessary. –

Check if the upper cover is properly ﬁ xed to the ﬁ lter chamber (clamps – 1 and 2

should be locked).To do this proceed according to the description under p.“A”.

Release the clamp at the bottom of the ﬁ ltration chamber, insert the FIZELINA –

(black insert) or do not insert it.

While vacuuming with the FIZELINA insert in place, the dust and dirt stored in

the ﬁ lter chamber above the FIZELINA are wet.

ATTENTION !!! You can use a disposable (quick replacement) or a reusable FIZELINA insert

(cheaper but requires washing or rinsing).

B – VACUUMING WITH A PAPER BAG AND WITH 1.5l-WATER AS AN ADDITIONAL FILTER

With these ﬁ ltration systems it is possible to operate the vacuum cleaner in one of the following modes:

A – VACUUMING WITH A PAPER BAG AND WITHOUT A WATER

Press the clamp and lift the upper cover. –

Take the front container out and remove the ﬁ lter from it. –

Release the clamps, which ﬁ x the upper cover to the ﬁ ltration –

chamber, by pressing it with your both thumbs, as shown on

the picture.

Lift the ﬁ lter handle until it reaches the vertical position, pull out –

the upper cover and open the dust-storage chamber.

The slots, which the paper bag can be attached to, are located

inside the chamber:

Fold the paper bag along the dashed line in the direction –

indicated by the arr.

Insert it vertically into the slot as indicated by the arrow on the –

picture. The hole in the paper bag should overlap with the ﬁ lter

inlet.

Bend the cardboard inwards (along the marked line) and lift the –

ﬁ lter handle until it is positioned vertically.

Insert the cover clamps into the rectangular slots, put the handle –

on the cover and lock it.

Press the upper cover with your thumbs at each clamp ( – 1 and

2 on the picture), either one by one or concurrently, until you

hear a click.

ATTENTION !!! Both clamps should always be locked!

Proceed as recommended for p.“A”.Then, do the following:

Release the clamp at the bottom of the ﬁ ltration chamber ( – 1).

Insert the white GORETEX ﬁ ltering insert (2) and press the

clamps.

Pour 1,5l of water into the front container.The water level should –

be between the MIN and MAX indications.

ATTENTION !!! Always use the “GORETEX” ﬁ ltering insert

while vacuuming with a paper bag.

After vacuuming do not leave the paper bag

in the ﬁ ltration chamber if there is water left in

the front container.

instrukcja 616-010.indb 118instrukcja 616-010.indb 118 2008-09-18 16:03:182008-09-18 16:03:18
