119

In this situation:

Switch the vacuum cleaner off by pressing the main switch and remove the plug –

from the socket.

Turn the hose until the ▼ symbols on the hose and the container are located –

opposite to each other.Remove the hose from the slot.

Open the upper cover and remove the front container. –

Take care to wrap the foam ﬁ lter around the ﬂ oat thoroughly (it is ﬁ xed with two fasteners).

Ensure that the gasket sticks to the container tightly. –

Insert the water ﬁ lter into the container –

and place the container on the base.

Close the upper cover. –

Insert the hose into the slot in the container so that the –

▼ symbols on the hose and the container are located

opposite to each other.Turn the hose to the left or right so

that these symbols are displaced.

Connect: –

a. the extension tube and the hose,

b. the extension tube and the nozzle or brush you

want to use.

Insert the plug into the mains socket equipped with an earth pin and start the –

vacuum cleaner by pressing the main switch.

ATTENTION !!! The vacuum cleaner is equipped with a ﬂ oat, which stops

suction automatically when the foam ﬁ lter gets too dirty.This is

demonstrated by an increased rpm of the motor.

Take the water ﬁ lter out of the container and remove the foam –

ﬁ lter.

Clean the ﬁ lters thoroughly (see: “When you have ﬁ nished –

vacuuming”).

Release the clamp at the bottom of the ﬁ ltration chamber and remove the dust –

collected.

If the dust was previously stored in a paper bag, release the upper cover clamps ( – 1)

as described under p. “A”.

Remove the dirty water from the container and rinse the container. –

Pour clean water, insert the water ﬁ lter, place the container on the base and close –

the upper cover.

Insert the plug into the mains socket equipped with an earth pin, start the vacuum –

cleaner and continue cleaning.

ATTENTION !!! The ﬂ oat can also stop suction as a result of sudden manoeuvres,

impacts or crossing the doorsteps.

In this situation:

Switch the vacuum cleaner off for a dozen of seconds, then switch it on and continue cleaning. –
