11 Technical data
Installer and user reference guide
24
FCAHG71~140FVEB
Split system air conditioners
4P429475-1 – 2015.12
11.7 Technical specifications: Indoor
unit
Technical specifications
FCAHG71 FCAHG100 FCAHG125 FCAHG140
Casing color Galvanised steel plate
Insulation
Heat insulation Foamed polystyrene/foamed polyethylene
Sound absorbing insulation Foamed polyurethane
Dimensions
Packing (H×W×D) 300×880×880mm
Unit (H×W×D) 288×840×840mm
Fan
Model QTS48D11M QTS48C15M
Type Turbo fan
Number of fans 1
Number of motors×output 48W 106W
Fan speed 5 steps
Piping connections
Liquid (outer diameter) Ø9.52mm (flare)
Gas (outer diameter) Ø15.9mm (flare)
Drain (outer diameter) Vinyl pipe 25mm (external diameter 32mm, internal diameter 25mm)
Refrigerant R32
Sound pressure level
High 36dBA 44dBA 45dBA
High medium 35dBA 42dBA 43dBA
Medium 33dBA 39dBA 40dBA
Medium low 31dBA 36dBA 38dBA
Low 29dBA 33dBA 35dBA
Electrical specifications
FCAHG71 FCAHG100 FCAHG125 FCAHG140
Power supply (from outdoor unit)
Phase 1~
Frequency 50Hz
Voltage 220-240V
Wiring connections
Connection to outdoor unit See "Connecting the electrical wiring"
