![Daikin FDYM60JEVLK [26/30] Specifications](/views2/1792763/page26/bg1a.png)
1-24
NOTE:
This product is not designed for repacking. In case of re-packing, contact to Daikin Dealer.
** Additional refrigerant charge of 0.2kg is needed in order to achieve the stated performance data.
MODEL INDOOR UNIT FDM20JEVLK FDM25JEVLK
OUTDOOR UNIT RD20JEVLK RD25JEVLK
RATED VOLTAGE V 220 220
RATED FREQUENCY Hz 60 60
COOLING (T1)
INDOOR
27DB
O
C/19WB
O
C
OUTDOOR
35DB
O
C/24WB
O
C
RATED CURRENT A 9.45 12.2
RATED POWER INPUT kW 2.01 2.61
CAPACITY Btu/h 19000 23300
kW 5.57 6.83
EER
(Btu/h)/W 9.45 8.92
COOLING (T3)
INDOOR
29DB
O
C/19WB
O
C
OUTDOOR
46DB
O
C/24WB
O
C
RATED CURRENT A 11.3 13.8
RATED POWER INPUT kW 2.41 2.97
CAPACITY Btu/h 16300 20000
kW 4.78 5.86
EER
(Btu/h)/W 6.76 6.73
NET WEIGHT INDOOR UNIT kg 25 28
OUTDOOR UNIT kg 49 57
REFRIGERANT R22 kg 1.60 1.80**
COUNTRY OF ORIGIN INDOOR UNIT
Malaysia
OUTDOOR UNIT
Malaysia
MODEL INDOOR UNIT
FDMY20JEVLK FDMY25JEVLK
OUTDOOR UNIT RYD20JEVLK RYD25JEVLK
RATED VOLTAGE V 220 220
RATED FREQUENCY Hz 60 60
COOLING (T1)
INDOOR
27DB
O
C/19WB
O
C
OUTDOOR
35DB
O
C/24WB
O
C
RATED CURRENT A 9.45 12.2
RATED POWER INPUT kW 2.01 2.61
CAPACITY Btu/h 19000 23300
kW 5.57 6.83
EER
(Btu/h)/W 9.45 8.92
COOLING (T3)
INDOOR
29DB
O
C/19WB
O
C
OUTDOOR
46DB
O
C/24WB
O
C
RATED CURRENT A 11.3 13.8
RATED POWER INPUT kW 2.41 2.97
CAPACITY Btu/h 16300 20000
kW 4.78 5.86
EER
(Btu/h)/W 6.76 6.73
HEATING
INDOOR
20DB
O
C/--WB
O
C
OUTDOOR
7DB
O
C/6WB
O
C
RATED CURRENT A 8.83 10.3
RATED POWER INPUT kW 1.88 2.20
CAPACITY Btu/h 21000 24500
W 6150 7180
COP W/W
3.27 3.26
NET WEIGHT INDOOR UNIT kg 25 28
OUTDOOR UNIT kg 49 57
REFRIGERANT R22 kg 1.60 1.80**
COUNTRY OF ORIGIN INDOOR UNIT
Malaysia
OUTDOOR UNIT
Malaysia
SPECIFICATIONS
1 IM-CCC-0311(0)-DAIKIN (SASO).i24 24 6/9/11 10:07:44 AM
