SATA Hard Drives Configurations (Intel ICH6R) - 2 -

Ác

Åé

¤¤

¤å

Configuring SATA Hard Drive(s) (Controller Intel ICH6R)

"*" Skip this step if you do not want to create RAID array on the SATA controller

To configure SATA hard drive(s), follow the steps below:

(1) Install SATA hard drive(s) in your system.

(2) Configure SATA controller mode and boot sequence in BIOS Setup.

(3)* Configure RAID set in RAID BIOS.

(4) Make a floppy disk containing the SATA controller driver.

(5) Install the SATA controller driver during OS installation.

Before you begin

Please prepare:

(a) Two SATA hard drives (to ensure optimal performance, it is recommended that you use two hard

drives with identical model and capacity). If you do not want to create RAID with the SATA

controller, you may prepare only one hard drive.

(b) An empty formatted floppy disk.

(d) Driver CD for your motherboard.

(1) Installing SATA hard drive(s) in your computer

Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available

SATA port(s) on the motherboard. (If there are more than one SATA controller on your motherboard, you

may check the name of the SATA connector to identify the SATA controller for the connector. For

example, SATA0_SB/SATA_SB is controlled by the SATA controller on South-Bridge.) Then connect the

power connector from your power supply to the hard drive.
