Gigabyte GA-8I915P Duo-A [11/88] English
![Gigabyte GA-8I915P Duo-A [11/88] English](/views2/1793125/page11/bgb.png)
Hardware Installation- 11 -
English
Onboard Audio C-Media 9880 CODEC (UAJ)
Supports Jack Sensing function
Supports 2 / 4 / 5.1 / 7.1 channel audio
Supports Line In ; Line Out ; MIC ; Back Surround Speaker Out ;
Center/Subwoofer Speaker Out ; Surround Speaker Out connection
Supports SPDIF In/Out connection
CD In
On-Board SATA RAID Onboard ICH6R chipset
supports data striping (RAID 0) or mirroring (RAID 1) function
supports JBOD function
supports data transfer rate of up 150 MB
supports hot plugging function
supports a maximum of 4 SATA connections
supported on the Win 2000/XP operating systems
On-Board IDE RAID Built-in VT6410 chipset
(IDE2, IDE3) Supports disk striping (RAID 0) or disk mirroring (RAID 1) or
striping + mirroring (RAID 0 + RAID 1)
Supports JBOD function
Supports concurrent dual ATA133 IDE controller operation
Supports ATAPI mode for HDD
Supports IDE bus master operation
Supports ATA133/RAID mode switch by BIOS
Displays status and error checking messages during boot-up
Mirroring supports automatic background rebuilds
Features LBA and Extended Interrupt 13 drive translation in
controller onboard BIOS
I/O Control IT8712
Hardware Monitor System voltage detection
CPU temperature detection
CPU / System / Power fan speed detection
CPU warning temperature
CPU / System / Power fan failure warning
CPU smart fan control
BIOS Use of licensed AWARD BIOS
Supports Dual BIOS /Q-Flash
Additional Features Supports @BIOS
Supports EasyTune
Overclocking Over Voltage via BIOS (CPU/DDR/PCI-E)
Over Clock via BIOS (CPU/DDR)
Form Factor ATX form factor; 30.5cm x 24.4cm
Only for GA-8I915P Duo Pro-A.
