Gigabyte GA-8N-SLI Quad Royal [11/112] English
![Gigabyte GA-8N-SLI Quad Royal [11/112] English](/views2/1793263/page11/bgb.png)
Hardware Installation- 11 -
English
Onboard Audio ALC850 CODEC
Supports 2 / 4 / 6 / 8 channel audio
Supports Line In ; Line Out (Front Speaker Out) ; MIC ; Surround Speaker
Out (Rear Speaker Out) ; Center/Subwoofer Speaker Out ; Side Speaker
Out connection
SPDIF_IN connection
SPDIF_Out (optical+coaxial) connection
CD_IN connection
I/O Control IT8712F
Hardware Monitor System voltage detection
CPU / NB / Power IC / temperature detection
CPU / System / Power / Auxilliary / Memory fan speed detection
CPU warning temperature
CPU / system / power fan failure warning
Onboard SATA 3Gb/s Onboard nVIDIA
®
CK804 chipset
RAID - supports data striping (RAID 0) or mirroring (RAID 1), striping +
mirroring (RAID 0+1) or RAID 5 function
- supports data transfer rate of up to 300 MB/s
- supports hot plugging function
- supports a maximum of 4 SATA 3Gb/s connections
- supported on the Win 2000/XP operating systems
BIOS Use of licensed AWARD BIOS
Supports Dual BIOS/Q-Flash/Multilanguage BIOS
Additional Features Supports @BIOS
Supports EasyTune 5
(Note 1)
Overclocking Over Voltage via BIOS (FSB/DIMM/PCIE/CPU/North Bridge/South Bridge)
Over Clock via BIOS (CPU/DIMM/PCIE)
Form Factor ATX form factor; 30.5cm x 24.4cm
(Note 1) EasyTune 5 functions may vary depending on different motherboards.
