FOR THE FOLLOWING ITEMS, TAKE SPECIAL CARE DURING CONSTRUCTION AND
CHECK AFTER INSTALLATION IS FINISHED.
1. Items to be checked after completion of work
2. Items to be checked at time of delivery *Also review the “SAFETY PRECAUTIONS”
Points for explanation about operations
3. NOTE TO THE INSTALLER
Be sure to instruct customers how to properly operate the unit (especially operating different functions,
and adjusting the temperature) by having them carry out operations themselves while looking at the
manual.
Items to be checked If not properly done, what is likely to occur Check
Are the indoor and outdoor unit fixed
firmly?
The unit may drop, vibrate or make noise.
Is the gas leak test finished? It may result in insufficient cooling.
Is the unit fully insulated? Condensate water may drip.
Does drainage flow smoothly? Condensate water may drip.
Does the power supply voltage
correspond to that shown on the name
plate?
The unit may malfunction or the components burn out.
Are wiring and piping correct?
The unit may malfunction or the components burn out.
Is the unit safely grounded? Dangerous at electric leakage.
Is wiring size according to specifications?
The unit may malfunction or the components burn out.
Is something blocking the air outlet or inlet
of either the indoor or outdoor units?
It may result in insufficient cooling.
Are refrigerant piping length and
additional refrigerant charge noted down?
The refrigerant charge in the system is not clear.
Items to be checked Check
Did you explain about operations while showing the instruction manual to your customer?
Did you hand the instruction manual over to your customer?
The items with WARNING and CAUTION marks in the instruction manual are the items
pertaining to possibilities for bodily injury and material damage in addition to the general usage of
the product. Accordingly, it is necessary that you make a full explanation about the described
contents and also ask your customers to read the instruction manual.
