Einhell TH-VC 1820 S [10/84] Technical data

Please note that our equipment has not been

designed for use in commercial, trade or industrial

applications. Our warranty will be voided if the

equipment is used in commercial, trade or industrial

businesses or for equivalent purposes.

4. Technical data

Mains voltage: 230 V ~ 50 Hz

Power input: 1.250 W

Container volume: 20 l

Weight: 5.0 kg

Protection class: II / 쏾

5. Before starting the equipment

 Important!

n Before you connect the equipment to the mains

supply make sure that the data on the rating

plate are identical to the mains data.

n The appliance may only be connected to a

shock-proof socket!

5.1 Appliance assembly

Fitting the appliance head (Fig. 4)

The appliance head (3) is fastened to the container

(7) by the locking hook (6). To remove the appliance

head (3), open the locking hook (6) and remove the

appliance head (3). When fitting the appliance head

(3), make sure that the locking hook (6) locks into

place correctly.

Assembling the wheels (Fig. 5)

Fit the wheels (13) in accordance with fig. 5.

Fitting the handle (Fig. 8)

Use a screwdriver to fit the handle (8).

Mounting the hook for the cable store (Fig. 12)

Press the hook for the cable store (19) into the mount.

After use, the power cable can be wound up onto the

hook (19) and the head (3).

5.2 Fitting the filter

 Important!

Never use the wet and dry vacuum cleaner without a

filter!

Always ensure that the filters are perfectly secure!

Fitting the foam filter (Fig. 6)

For wet-vacuuming, slip the supplied foamed plastic

filter (15) over the filter basket (Figs. 2/4).

Fitting the additional filter (Fig. 7)

For dry vacuum cleaning always use the supplied

additional filter (18). Mount the additional filter, so

that no air is sucked through the filter cage (4)

without being filtered.

Assembling the dirt bag (Fig. 9)

For vacuuming fine, dry dirt it is recommended that

you fit the dirt bag (14). Slip the dirt bag (14) over the

vacuuming hole. The dirt bag (14) is suitable for dry-

vacuuming only. The dirt bag makes it easier to

dispose of the sucked-in dust.

5.3 Fitting the suction hose (Fig. 3, 10, 11)

Connect the suction hose (10) to the corresponding

connector on the wet and dry vacuum cleaner,

depending on the application required.

Vacuuming

Connect the suction hose (10) to the suction hose

connector (8)

Blowing

Connect the suction hose (10) to the blow connector

(9)

One or more of the elements which make up the 3-

part suction tube (11) can be attached to the suction

hose (10) to extend it. The adapter (17) must be

inserted between the suction tube (10) and the

combination nozzle (12) or crevice nozzle (16).

5.4 Suction nozzles

Combination nozzle (12)

The combination nozzle (12) with attachments is for

vacuuming solids and liquids over medium to large

areas. The crevice nozzle (16) is specially designed

for cleaning cervices and edges.

Anleitung_TH_VC_1820_S_SPK7__ 21.06.13 08:50 Seite 10
