Gigabyte 8VM800M-RZ [5/40] Chapter 1 introduction
![Gigabyte 8VM800M-RZ [5/40] Chapter 1 introduction](/views2/1795916/page5/bg5.png)
Introduction
English
- 5 -
CPU y Socket 478 for Intel
®
Pentium
®
4(Northwood, Prescott) with HT Technology
y Intel
®
Pentium
®
4 533/400MHz FSB
y 2nd cache depends on CPU
Chipset y Northbridge : VIA PM800
y Southbridge : VIA 8237R
Memory y 2 184-pin DDR DIMM sockets, supports up to 2GB DRAM (Max)
y Supports DDR400/DDR333/DDR266 DIMM
Slots y 1 AGP slot supports 8X/4X(1.5V) mode
y 3 PCI slots
On-Board IDE y 2 IDE controller provide IDE HDD/CD-ROM(IDE1, IDE2) with PIO, Bus
Master (Ultra DMA33/ATA66/ATA100/ATA133) operation modes
y Can connect up to 4 IDE devices
On-Board Floppy y 1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M and 2.88M bytes
On-Board SATA y 2 Serial ATA connectors
(Note)
On-Board Peripherals y 1 Parallel port supports Normal/EPP/ECP mode
y 1 Serial port (COMA), 1 VGA port, COMB on-board
y 8 USB 2.0/1.1 ports (4 x Rear, 4 x Front by cable)
y 1 Front audio connector
y 1 PS/2 keyboard
y 1 PS/2 mouse
On-Board VGA y Built-in VIA PM800
On-Board LAN y Builit-in VIA VT6103L chipset
y 1 RJ45 port
On-Board Sound y CMI 9761 codec
y Supports 2/4/6-channel
y Line Out / Line In / Mic In
y SPDIF In / Out
y CD In / Game connector
On-Board SATA RAID y Built-in VIA VT8237R
y Supports disk striping (RAID 0) or disk mirroring (RAID 1)
y Supports up to 150MB/s data transfer rate
y Supports hot plug function
y Up to 2 SATA devices
BIOS y Licensed AWARD BIOS
y Supports Q-Flash
I/O Control y IT8705
Hardware Monitor y CPU/System fan revolution detect
y CPU temperature detect
y System voltage detect
y CPU/System fan fail warning
y Thermal shutdown function
Chapter 1 Introduction
Features Summary
(Note) It is recommended to use SATA (1.5Gb/s) hard disks.
