4 | Operation
User reference guide
37
EHYHBH05AF + EHYHBH/X05+08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355632-1E – 2020.10
User profile = Basic User profile = Detailed
15:20
20.0°C
Mon
Room
Actual temperature
15:20
20.0°C
17:30
Actual temperature
Room
Scheduled
Mon
Tue
To configure which home pages are made available to the enduser
Prerequisite: You switched the permission level to Advanced end user.
1 Go to [7.1.4]: > User settings > Display > Available home pages.
Result: The home pages that are possible for your system layout are listed.
2 Select a home page and press .
3 Do one of the following:
▪ To display the home page, select Yes and press .
▪ To hide the home page, select No and press .
4.6.7 Locking and unlocking buttons and functions
About locking and unlocking
You can use the following locking modes:
▪ Button lock: Locks all buttons to prevent children from changing settings.
▪ Function lock: Locks a specific function to prevent people from changing its
settings.
Possible function locks
Lock If active, people cannot…
Room On/OFF Turn ON or OFF the room temperature
control.
LWT On/OFF Turn ON or OFF the leaving water
temperature (main + additional)
control.
Tank On/OFF Turn ON or OFF the domestic hot water
control.
Temperature up/down Adjust temperatures.
Quiet mode Use quiet mode.
Holiday Use holiday mode.
Operation mode Set the space operation mode.
User settings Change settings in [7]: > User
settings.
DHW On/OFF Turn ON or OFF the instant hot water
control.
To check if locking is active
1 Press to go to one of the home pages.
2 If is displayed, button lock is active.
