4 | Operation
User reference guide
45
EHYHBH05AF + EHYHBH/X05+08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355632-1E – 2020.10
[7.6]
Units of measurement
Decimal point
Temperature
Pressure
Produced energy
[7.7]
Set weather dependent
Main
Additional
[7.7.1]
Main
Set weather-dependent heating
Set weather-dependent cooling
[7.7.2]
Additional
Set weather-dependent heating
Set weather-dependent cooling
Flow
Consumed gas
INFORMATION
Depending on the selected installer settings and unit type, settings will be visible/
invisible.
4.10 Installer settings: Tables to be filled in by installer
4.10.1 Quick wizard
Setting Default Fill in…
Forced off contact [A.2.1.6]
Forced off contact 0 (No)
Space heating/cooling settings [A.2.1]
Unit control method 2 (RT control)
User interface location 1 (In room)
Number of LWT zones 0 (1 LWT zone)
Pump operation mode 2 (Request)
Domestic hot water settings [A.2.2]
DHW operation Depends on model
DHW pump 0 (No)
Thermostats [A.2.2]
Contact type main 2 (H/C request)
Contact type add. 2 (H/C request)
External sensor 0 (No)
Digital I/O PCB [A.2.2.6]
Solar kit 0 (No)
Alarm output 0 (Normally open)
Demand PCB [A.2.2.7]
Demand PCB 0 (No)
