54
ENG
pRack PR300T +0300018EN rel. 1.5 - 02.05.2017
Mask index Display description Description Def. U. of M.Values
A. Unit status
Aa01 (display
only)
Pressure Suction pressure (line 1) --- … …(**)
Sat.Temp. Suction saturated temperature (line 1) --- … …(**)
ActualSet Actual setpoint for pressure regulation (with compensations applied, line 1) --- … …(**)
Di eren. Regulation di erential for pressure regulation (line 1) --- … …(**)
Aa02 (display
only)
Pressure Suction pressure (line 1) --- … …(**)
Sat.Temp. Suction saturated temperature (line 1) --- … …(**)
ActualSet Actual setpoint for temperature regulation (with compensations applied, line 1) --- … …(**)
Di eren. Regulation di erential for temperature regulation (line 1) --- … …(**)
Aa03 (display
only)
Act/Req. Power delivered/Power requested per suction line (line 1) --- % 0 | 0 …100 | 100
Reg. Status Regulation status (according to the type of regulation set, line 1) --- --- Stop | Increase
Decrease
Stand-by
Functioning
Timings | Alarms
Reg. Type Compressor regulation type (line 1) --- --- Proportional Band
Dead Zone
Setpoint Actual suction setpoint (with compensations applied, line 1) --- … …(**)
Aa04 (display
only)
C01, C02, …C12 Time remaining for next compressor startup (line 1) --- s 0…32000
C01 Power delivered from compressor 1 of line 1 (a "!" to the right of the value means that some
form of compressor power forcing is active, e.g., safety times, alarms, startup procedure)
--- % 0…100
…… ………
C12 Power delivered from compressor 12 (line 1) --- % 0…100
Aa05 (display
only)
Temperature Suction temperature (line 1) --- … …(**)
Superheat. Superheating (line 1) --- … …(**)
Aa11 (display
only)
Disch. 1 Discharge temperature compressor 1 (line 1) --- … …(**)
…… ………
Disch. 6 Discharge temperature compressor 6 (line 1) --- … …(**)
Aa12 (display
only)
Oil Temp 1 Oil temperature compressor 1 (line 1) --- … …(**)
…… ………
Oil Temp 6 Oil temperature compressor 6 (line 1) --- … …(**)
Aa13 (display
only)
In.liq.1: DO Digital output number associated and liquid injection/economizer (*) status compressor 1
(line 1)
--- … 0…29
…… ………
In.liq.6: DO Digital output number associated and liquid injection/economizer (*) status compressor 6
(line 1)
--- … 0…29
Aa15 (display
only)
Discharge temperature Discharge temperature Digital Scroll
TM
compressor (line 1) --- … …(**)
Cap.Reduction Capacity reduction Digital Scroll
TM
compressor (line 1) in progress NO | YES
Oil sump T. Oil sump temperature Digital Scroll
TM
compressor (line 1) --- … …(**)
Oil status Oil dilution status Digital Scroll
TM
compressor (line 1) OK | Diluted
Aa16 (display
only)
Status Operational status Digital Scroll
TM
compressor (line 1) --- --- OFF | Start
ON | Alarm
Count Safety time count Digital Scroll
TM
compressor (line 1) --- s 0…999
Compr. Status Digital Scroll
TM
compressor (line 1) --- --- ON | OFF
Valve Status Digital Scroll
TM
valve (line 1) --- --- ON | OFF
Cap.Req. Capacity requested Digital Scroll
TM
compressor (line 1) --- % 0…100
ActualCapac. Actual capacity Digital Scroll
TM
compressor (line 1) --- % 0…100
Aa20 (display
only)
Pressure Condensing pressure (line 1) --- … …(**)
Sat.Temp. Condensing saturated temperature (line 1) --- … …(**)
ActualSet Actual setpoint for pressure regulation (with compensations applied, line 1) --- … …(**)
Di eren Regulation di erential for pressure regulation (line 1) --- … …(**)
Aa21 (display
only)
Pressure Condensing pressure (line 1) --- … …(**)
Sat.Temp. Condensing saturated temperature (line 1) --- … …(**)
ActualSet Actual setpoint for temperature regulation (with compensations applied, line 1) --- … …(**)
Di eren. Regulation di erential for temperature regulation (line 1) --- … …(**)
Aa22 (display
only)
Act/Req Power delivered/Power requested per condensing line (line 1) --- % 0 | 0 …100 | 100
Reg. Status Regulation status (according to the type of regulation set, line 1) --- --- Stop | Increase
Decrease
Stand-by
Functioning
Timings | Alarms
Reg. Type Gas cooler regulation type (line 1) --- --- Proportional Band
Dead Zone
Setpoint Actual setpoint gas cooler (line 1) --- … …(**)
Aa23 (display
only)
F1 Power delivered from fan 1 of line 1 (a "!" to the right of the value means that some form of
power forcing is active)
--- % 0…100
…… ………
F8 Power delivered from fan 8 of line 1 (a "!" to the right of the value means that some form of
power forcing is active)
--- % 0…100
Aa24 (display
only)
F9 Power delivered from fan 9 of line 1 (a "!" to the right of the value means that some form of
power forcing is active)
--- % 0…100
…… ………
F16 Power delivered from fan 16 of line 1 (a "!" to the right of the value means that some form of
power forcing is active)
--- % 0…100
Aa25 (display
only)
Discharge temperature Discharge temperature (line 1) --- … …(**)
External temperature External temperature (line 1) --- … …(**)
Aa31 (display
only)
Pressure Suction pressure (line 2) --- … …(**)
Sat.Temp. Suction saturated temperature (line 2) --- … …(**)
ActualSet Actual setpoint for pressure regulation (with compensations applied, line 2) --- … …(**)
Di eren. Regulation di erential for pressure regulation (line 2) --- … …(**)
Aa32 (display
only)
Pressure Suction pressure (line 2) --- … …(**)
Sat.Temp. Suction saturated temperature (line 2) --- … …(**)
ActualSet Actual setpoint for temperature regulation (with compensations applied, line 2) --- … …(**)
Di eren. Regulation di erential for temperature regulation (line 2) --- … …(**)
Aa33 (display
only)
Act/Req. Power delivered/Power requested per suction line (line 2) --- % 0 | 0 …100 | 100
Reg. Status Regulation status (according to the type of regulation set, line 2) --- --- Stop | Increase
Decrease
Stand-by
Functioning
Timings | Alarms
Reg. Type Compressor regulation type (line 2) --- --- Proportional Band
Dead Zone
Setpoint Actual suction setpoint (with compensations applied, line 2) --- … …(**)
Page 110 of 177
Copyright HPL January 2021
P4115S Rev 02
Содержание
- Gcu4070pxb1 1
- Technical manual a rev 02 1
- Contents 2
- Model gcu4070pxb1 3
- C a10145 10m signed doc2 4
- Hubbard hermetic rotary r744 units 5
- Installation commissioning and maintenance 5
- Installation manual 10hp 5
- Manual 5
- Model no gcu4070pxb1 5
- On siting the unit we recommend the security of all electrical connections is checked and system flanges rotalock valves and flexible connections are secure where flexible hose lines are used please ensure that the outer material is not subject to rupture due to contact with other surfaces before initial operation we recommend that crankcase heaters are operated for 24 hours prior to compressor operation to ensure correct lubrication properties are provided the units are factory tested including leak pressure and electrical test not running test anyway is highly recommend a further pressure test after transport and positioning to help prevent leakage in operation pressure testing should be carried out according to your companies test procedures and where applicable in accordance current p e d recommendations f gas regulations and your customers requirements 9
- Models gcu4070pxb1 10
- Both k65 12
- Gcu4070pxb1 12
- Suction line 1 2 liquid line 1 2 12
- Gcu4070pxb1 22
- Material sds 27
- Materials in the system 27
- A sds r744co2 28
- Material safety data sheet 28
- Daphne hermetic oil pz68s 35
- Safety data sheet 35
- Section 1 identification of the substance mixture and of the company undertaking 35
- Section 2 hazards identification 35
- Daphne hermetic oil pz68s 36
- Section 3 composition information on ingredients 36
- Section 4 first aid measures 36
- Daphne hermetic oil pz68s 37
- Section 5 firefighting measures 37
- Section 6 accidental release measures 37
- Section 7 handling and storage 37
- Daphne hermetic oil pz68s 38
- Section 8 exposure controls personal protection 38
- Section 9 physical and chemical properties 38
- Daphne hermetic oil pz68s 39
- Section 10 stability and reactivity 39
- Daphne hermetic oil pz68s 40
- Section 11 toxicological information 40
- Daphne hermetic oil pz68s 41
- Section 12 ecological information 41
- Section 13 disposal considerations 41
- Section 14 transport information 41
- Daphne hermetic oil pz68s 42
- Section 15 regulatory information 42
- Daphne hermetic oil pz68s 43
- Section 16 other information 43
- Model gcu4070pxb1 45
- Wiring schematics 45
- 2 d4156s 04 46
- 7 bluestem road ransomes europark 46
- An 25 02 2019 46
- B d4156s rev 04 46
- Copyright hpl january 2021 p4115s rev 02 46
- D4156s rev 04 10hp mt ccu short form diagram sh1 46
- Hp mt ccu wiring diagram short form 46
- If in doubt ask 46
- Page 46 of 177 46
- Suffolk ipswich ip3 9rr tel 01473 890522 fax 01473 890687 46
- 7 bluestem road ransomes europark 47
- An 25 02 2019 47
- Copyright hpl january 2021 p4115s rev 02 47
- D4156s 04 47
- D4156s rev 04 10hp mt ccu short form diagram sh2 47
- Hp mt ccu wiring diagram short form 47
- If in doubt ask 47
- Page 47 of 177 47
- Suffolk ipswich ip3 9rr tel 01473 890522 fax 01473 890687 47
- C wiring schematics 48
- Model gcu4070pxb1 48
- D d4468 49
- Model gcu4070pxb1 54
- Part number d4161 54
- Pipework schematics 54
- B d4161co2 schematic 10hp with intercooler 55
- Copyright hpl january 2021 p4115s rev 02 55
- Hp single compressor co2 pipework schematic 55
- Iam 12 09 2018 d4161 p8 55
- If in doubt ask 55
- P5 17 09 19 55
- P6 24 10 19 55
- P7 29 10 19 55
- P8 25 03 20 55
- Page 55 of 177 55
- Carel controller manual 56
- A carel pr300t_latest 57
- Carel reserves the right to modify the features of its products without prior notice 58
- Copyright hpl january 2021 p4115s rev 02 58
- Disposal 58
- Important 58
- Page 58 of 177 58
- Warning 58
- Content 59
- Functions 32 59
- Hardware characteristics and installation 7 59
- Installation 21 59
- Introduction 5 59
- Start up 26 59
- User interface 29 59
- Alarms 83 60
- Appendix 94 60
- Parameters and alarms table 53 60
- Software update and configuration 87 60
- Supervisory and commissioning systems 86 60
- Components and accessories 61
- Introduction 61
- Main features 61
- Pr300t functionality list 61
- Code description pgderk1fx0 pgd evolution user terminal for prack pr300t 62
- Confi guration of the system and confi guration of the inputs and outputs 62
- Convonoff0 module to convert a 0 0v analog output to an spdt digital output cvstdutlf0 usb rs485 serial convertor with telephone connector cvstdumor0 usb rs485 serial converter with 3 way terminal pcoso0aky0 smart key programming key s90conn002 connection cable for terminal 1 0 m s90conn000 connection cable for terminal 1 1 m s90conn001 connection cable for terminal 1 3 m spkt r and spkc00 ratiometric pressure probes 0 5 vdc 62
- Copyright hpl january 2021 p4115s rev 02 62
- Evdis00d 0 display for evd evo e2vcabs 00 evd valve connection cable 62
- Fieldbus card bms card 62
- J1 j24 j2 j3 j4 j5 62
- J11 plan 62
- J13 j12 j15 62
- J25 bms2 j26 fbus2 62
- Ntc pressure probe ntc 50t90 c ntc ht pressure probe ntc 0t150 c evd0000e50 evd evo universal driver for carel valves rs485 modbu 62
- Page 62 of 177 62
- Pr300t 62
- Pr300t pr300t 62
- Prack pr300t 0300018en rel 1 02 5 017 62
- Spk c spk1 spk2 spk3 active pressure probes 4 20 ma 62
- System confi gurations available 62
- 5 1 6 2 3 3 3 8 9 7 8 63
- Analogue outputs 17 fieldbus2 connector 8 id digital inputs for voltage a 18 jumpers for selecting fieldbus bms 63
- Copyright hpl january 2021 p4115s rev 02 63
- Fieldbus card bms card 63
- Fig 2 a 63
- Fig 2 b 63
- Hardware characteristics and installation 63
- Id digital inputs for voltage a idh digital inputs for voltage b 10 plan telephone connector for terminal downloading application voltage a 24 vac or 28 to 36 vdc voltage b 230 vac 50 60 hz 63
- J1 j24 j2 j3 j4 j5 63
- J1 j24 j2 j3 j4 j5 j7 j8 63
- J11 plan 63
- J13 j12 j15 63
- J13 j12 j16 j17 j18 j15 63
- J25 bms2 j26 fbus2 63
- Page 63 of 177 63
- Pr300t 63
- Prack 300 s m d l board description 63
- Prack pr300t 0300018en rel 1 02 5 017 63
- Prack pr300t m 63
- Prack pr300t s 63
- Ref description ref description 1 power supply connector g g0 11 plan plug in connector 63
- Tab 2 a 63
- Universal inputs outputs 13 reserved 4 vdc power supply for active probes 14 reserved 5 button for setting plan address second display led 15 relay digital outputs 63
- Vg power supply at voltage a for opto isolated analogue output vg0 power to opto isolated analogue output 0 vac vdc 16 bms2 connector 63
- Vterm power supply for additional terminal 5 vref power supply for ratiometric probes 12 reserved 63
- 11 12 15 64
- 5 1 6 2 3 3 64
- 5 1 6 2 3 3 3 8 9 7 8 64
- A b c d 64
- Fieldbus card bms card 64
- J1 j24 j2 j3 j4 j5 64
- J1 j24 j2 j3 j4 j5 j7 64
- J11 plan 64
- J13 j12 64
- J13 j12 j16 j17 j18 j15 64
- J16 j17 j18 j15 64
- J23 fbus2 64
- J25 bms2 j26 fbus2 64
- J25 bms2 j26fbus2 64
- N c model 64
- Pr300t 64
- Prack pr300t 0300018en rel 1 02 5 017 64
- Electrical specifi cations 65
- Physical specifi cations 65
- Technical specifi cations 65
- Digital inputs id idh 66
- For dc voltage inputs 24 vdc either the or the can be connected to common terminal 66
- Id1 id8 id9 to id12 id17 id18 have functional insulation from the rest of the controller 66
- Power supply to probes and terminals 66
- Separate as much as possible the probe and digital input cables from cables to inductive loads and power cables so as to avoid possible electromagnetic disturbance never run power cables including the electrical panel cables and signal cables in the same conduits 66
- The rating of the external contact connected to the digital inputs must be at least 5 ma 66
- The two 230 vac or 24 vac vdc inputs on terminals j8 id13 id14 or j19 id15 id16 have the same common pole and therefore both will operate at 230 vac or 24 vac vdc there is basic insulation between the two inputs there is reinforced insulation between the inputs and the rest of the controller 66
- Universal inputs outputs u 66
- A 0 to 10 vdc analogue output can be connected in parallel to other outputs of the same type or alternatively to an external source of voltage the higher voltage will be considered correct operation is not guaranteed if actuators with voltage inputs are connected 67
- Analogue outputs y 67
- Digital outputs no nc 67
- M only use shielded cable with the shield connected to earth 67
- Power the vg vg0 analogue outputs at the same voltage on g g0 connect g0 to vg0 and g to vg this is valid for both alternating and direct current power supplies 67
- Relays with the same insulation 67
- Ssr outputs in models where featured 67
- Model with electronic expansion valve driver 68
- Serial port 68
- 24 vdc or 24 vac power supply 69
- Meaning of the inputs outputs on the prack pr300t s m l boards 69
- Normally open contact relay no 3 69
- Fig 2 e 70
- Prack pr300t s m d l board dimensions 70
- Bianco nero 71
- Copyright hpl january 2021 p4115s rev 02 71
- Fieldbus card bms card 71
- J1 j24 j2 j3 j4 j5 71
- J11 plan 71
- J13 j12 j15 71
- J25 bms2 j26 fbus2 71
- Max 6 sonde attive 71
- Nero bianco 71
- Non usato per altri tipi di sensori 4 20 ma fare riferimento al relativo foglio di istruzioni 71
- Out 3 out 2 out 1 71
- Page 71 of 177 71
- Pgde prack 71
- Pr300t 71
- Prack pr300t 0300018en rel 1 02 5 017 71
- Prack pr300t general connection diagram 71
- Rs485 bms connections 71
- Vac 230 vac 0 vac vdc 71
- Vac 230 vdc 0 vac vdc 71
- Vac vdc 0 vac vdc 71
- Vac vdc 24 vac vdc 71
- 24 vac ac v v dc dc 72
- Bianco nero 72
- Copyright hpl january 2021 p4115s rev 02 72
- Fieldbus card bms card 72
- Fig 2 g 72
- J1 j24 j2 j3 j4 j5 j7 j8 72
- J11 plan 72
- J13 j12 j16 j17 j18 j15 72
- J25 bms2 j26 fbus2 72
- Max 6 sonde attive 72
- Medium 72
- Nero bianco 72
- Non usato per altri tipi di sensori 4 20 ma fare riferimento al relativo foglio di istruzioni 72
- Page 72 of 177 72
- Pr300 pr300 72
- Pr300t 72
- Prack pr300t 0300018en rel 1 02 5 017 72
- Rs485 bms connections 72
- Va va c c vd vd c 72
- Vac 230 vac 0 vac vdc 72
- Vac 230 vdc 0 vac vdc 72
- Vac vdc 0 vac vdc 72
- Vac vdc 230 vac 0 vac vdc 72
- Vac vdc 24 vac vdc 72
- Bianco nero 73
- Black white 73
- Copyright hpl january 2021 p4115s rev 02 73
- Fieldbus card bms card 73
- J1 j24 j2 j3 j4 j5 j7 73
- J11 plan 73
- J13 j12 73
- J16 j17 j18 j15 73
- J23 fbus2 73
- J25 bms2 j26 fbus2 73
- Max 6 sonde attive 73
- Nero bianco 73
- Non usato per altri tipi di sensori 4 20 ma fare riferimento al relativo foglio di istruzioni 73
- Out 5 out 6 73
- Page 73 of 177 73
- Pgde prack 73
- Pr300 pr300 73
- Pr300t 73
- Prack pr300t 0300018en rel 1 02 5 017 73
- Rs485 bms connections 73
- Vac 230 vac 0 vac vdc 73
- Vac vdc 73
- Vac vdc 0 vac vdc 73
- Vac vdc 24 vac vdc 230 vac 0 vac vdc 73
- Alco ex5 6 ex7 8 74
- Bianco nero 74
- Bianco white 74
- Coma noa 74
- Connessioni ad altri tipi di valvole 74
- Copyright hpl january 2021 p4115s rev 02 74
- Driver integrato 74
- Fieldbus card bms card 74
- Fig 2 i 74
- G g0 vbat 74
- Giallo yellow 74
- J1 j24 j2 j3 j4 j5 j7 j8 74
- J11 plan 74
- J13 j12 j16 j17 j18 j15 74
- J25 bms2 j26 fbus2 74
- Legenda 1 verde 3 bianco 5 nero 2 marrone 4 rosso 6 blu 74
- Marrone brown 74
- Max 6 sonde attive 74
- Nero bianco 74
- Non usato per altri tipi di sensori 4 20 ma fare riferimento al relativo foglio di istruzioni 74
- Ntc driver a 74
- Ntc driver b 74
- Page 74 of 177 74
- Pr300 pr300 74
- Pr300t 74
- Prack pr300t 0300018en rel 1 02 5 017 74
- Ratiometric pressure transducer driver a 74
- Ratiometric pressure transducer driver b 74
- Rs485 bms connections 74
- Shield 74
- Sporlan sei seh ser danfoss ets ccm ccmt 74
- V valve a carel 74
- V valve b 74
- Vac vdc 0 vac vdc 74
- Verde green 74
- Alco ex5 6 ex7 8 75
- Applicabile a s m l d 75
- Coma noa 75
- Connessioni ad altri tipi di valvole 75
- Copyright hpl january 2021 p4115s rev 02 75
- Dedicato 75
- Driver esterno 75
- Fieldbus card bms card 75
- G g0 vbat 75
- Indirizzo seriale 198 75
- J1 j24 j2 j3 j4 j5 75
- J11 plan 75
- J13 j12 j15 75
- J25 bms2 j26 fbus2 75
- Legenda 1 verde 3 bianco 5 nero 2 marrone 4 rosso 6 blu 75
- Ntc driver a 75
- Ntc driver b 75
- Page 75 of 177 75
- Pr300 pr300 75
- Pr300t 75
- Prack pr300t 0300018en rel 1 02 5 017 75
- Ratiometric pressure transducer driver a 75
- Ratiometric pressure transducer driver b 75
- Rs485 bms connections 75
- Shield 75
- Sporlan sei seh ser danfoss ets ccm ccmt 75
- Va tradrfe240 75
- Vac 230 vac 75
- Enable cpcoe no 76
- Enable i o expansion board management no 76
- Expansion card 76
- Offline pattern dis digital output pattern 1 off 2 off 3 off 4 off 5 off 6 off 76
- Wizard ib1f 76
- Anchoring the prack pr300t 77
- Connecting the analogue inputs 77
- General installation instructions 77
- Installation 77
- Installation procedure 77
- Power supply 77
- Wiring procedure 77
- Pr300t 78
- Connecting 0 10 v active probes 79
- Connecting the analogue inputs selected as on off 79
- Connecting the digital inputs 79
- Remote connection of the analogue inputs 79
- Vac digital inputs 79
- Vdc digital inputs 79
- Connecting 0 10 v analogue outputs 80
- Connecting the analogue outputs 80
- Connecting the digital outputs 80
- Electromechanical relay digital outputs 80
- Optional modules 80
- Remote connection of the digital inputs 80
- Vac digital inputs 80
- Connecting the terminals 81
- Copyright hpl january 2021 p4115s rev 02 81
- Page 81 of 177 81
- Plan electrical connections 81
- Remote connection of the digital outputs 81
- Solid state relay ssr digital outputs 81
- Summary table of digital outputs according to the versions available 81
- Answer the questions to have a fully configuration 82
- Example of system confi guration using the wizard 82
- Select config item wizard 82
- Start up 82
- Starting the fi rst time 82
- Wizard 82
- Configure another condensing line no 83
- Enable i o config yes 83
- Rprv status connected 83
- Visualize wizard report no push down to continue 83
- Wizard ib98 83
- Wizard ib99 83
- Advanced confi guration 84
- Associating the inputs and outputs 84
- Press enter to continue 84
- Successfully complete 84
- Wizard 84
- Description of the display 85
- Double line config 85
- Gas cooler 64 4barg unit off by keyboard 85
- Graphic terminal 85
- I1 i3 i2 i4 85
- I1 value l1 compr i2 value l2 compr 85
- I3 value l1 fans i4 value hpv 85
- Main mask config fb10 85
- Prack 14 30 20 01 10 suction l1 26 6barg l2 12 6barg 85
- User interface 85
- Barg 0 barg 0 barg 86
- L1 ai status bab01 suction press probe plb1 b1 4 20ma 86
- Password 86
- Upper value lower value calibration 86
- Menu description 87
- Functions 88
- Plan 1 address 88
- Plan 2 address 88
- Schematic diagram and system confi gurations used 88
- C1 c2 c3 c4 89
- Control 89
- Devices activation 89
- Differential differential 89
- Regulation probe value 89
- Regulation request 89
- Setpoint 89
- Suction pressure differential differential 89
- Unit on off 89
- Decrease zone increase zone neutral zone 100 90
- Diff diff 90
- Force off 90
- Modulation in neutral zone 90
- Neutral zone 90
- Regulation probe value 90
- Regulation request 90
- Regulation variable p i 90
- Setpoint 90
- 50 75 100 91
- C2 c3 c4 91
- Compressors 91
- Control with backup probes and or probes not working 91
- Possible compressor confi gurations 91
- Rotation 91
- Rotation with modulation devices 92
- Balancing 93
- Compressor request 93
- Economizer 93
- Liquid injection 93
- Manual operation 93
- Part winding 93
- Safety times 93
- Starting 93
- Compressor 1 force to off 94
- D01 no off 94
- D02 no off 94
- Digital output board1 94
- Manual mng bba02 94
- Test do bca10 94
- Control 95
- Gas cooler 95
- Alarms 96
- Fast start speed up 96
- Hpv valve management 96
- Manual operation 96
- Rotation 96
- Silencer 96
- Split condenser 96
- Setpoint hpv 97
- Rprv valve accessory functions 98
- Rprv valve management 98
- Summary of inputs outputs and hpv valve par 98
- Summary of inputs outputs and rprv valve parameters 98
- Booster system use l1 suct probe for condensing line 2 no prevent disabled disch press needed 99
- Configure intercooler between the suction lines 99
- Energy saving 99
- Intercooler 99
- L2 prevent gbb07 99
- Wizard ib98 99
- Accessory functions 100
- Floating condensing set point 100
- Floating suction set point 100
- Individual compressor oil management 100
- Oil management 100
- Oil management per line 100
- Summary of inputs outputs and oil parameters 101
- Subcooling 102
- Summary of inputs outputs and oil injection parameters 102
- Summary of inputs outputs and oil receiver level parameters 102
- Heat recovery 103
- Hr2 gas cooler 103
- Generic functions 104
- Chillbooster 105
- Double line synchronization dss 105
- Eevs electronic expansion valve synchronization 105
- Hpv and rprv valve connection 105
- A line 1 b line 2 c parallel compression 106
- Compressors 3 3 106
- Control mode external plan 106
- Liquid non return 106
- Parallel compr cca01 enable parallel compressor yes 106
- Parallel compressor 106
- Sign of life 106
- Unit of measure 106
- Control mode internal 107
- Parallel compr cca01 enable parallel compressor yes 107
- Managing the default values 108
- Resetting the carel default values 108
- Saving and resetting the user default values 108
- Settings 108
- Time bands 108
- B in out a status b analog in 109
- Parameter table 109
- Parameters and alarms table 109
- Prack pr300t 0300018en rel 1 02 5 017 109
- A unit status 110
- Copyright hpl january 2021 p4115s rev 02 110
- Page 110 of 177 110
- Copyright hpl january 2021 p4115s rev 02 111
- Page 111 of 177 111
- Prack pr300t 0300018en rel 1 02 5 017 111
- Copyright hpl january 2021 p4115s rev 02 112
- Page 112 of 177 112
- Prack pr300t 0300018en rel 1 02 5 017 112
- Copyright hpl january 2021 p4115s rev 02 113
- Page 113 of 177 113
- Tab 7 b 113
- Copyright hpl january 2021 p4115s rev 02 114
- Page 114 of 177 114
- Prack pr300t 0300018en rel 1 02 5 017 114
- Copyright hpl january 2021 p4115s rev 02 115
- Page 115 of 177 115
- Tab 7 c 115
- Copyright hpl january 2021 p4115s rev 02 116
- Page 116 of 177 116
- Prack pr300t 0300018en rel 1 02 5 017 116
- Copyright hpl january 2021 p4115s rev 02 117
- Page 117 of 177 117
- Prack pr300t 0300018en rel 1 02 5 017 117
- Copyright hpl january 2021 p4115s rev 02 118
- Page 118 of 177 118
- Tab 7 d 118
- Copyright hpl january 2021 p4115s rev 02 119
- Page 119 of 177 119
- Prack pr300t 0300018en rel 1 02 5 017 119
- Copyright hpl january 2021 p4115s rev 02 120
- Page 120 of 177 120
- Prack pr300t 0300018en rel 1 02 5 017 120
- Copyright hpl january 2021 p4115s rev 02 121
- Page 121 of 177 121
- Tab 7 e 121
- Copyright hpl january 2021 p4115s rev 02 122
- Page 122 of 177 122
- Prack pr300t 0300018en rel 1 02 5 017 122
- Copyright hpl january 2021 p4115s rev 02 123
- Page 123 of 177 123
- Prack pr300t 0300018en rel 1 02 5 017 123
- Copyright hpl january 2021 p4115s rev 02 124
- Page 124 of 177 124
- Prack pr300t 0300018en rel 1 02 5 017 124
- Copyright hpl january 2021 p4115s rev 02 125
- Page 125 of 177 125
- Prack pr300t 0300018en rel 1 02 5 017 125
- Copyright hpl january 2021 p4115s rev 02 126
- Page 126 of 177 126
- Prack pr300t 0300018en rel 1 02 5 017 126
- Copyright hpl january 2021 p4115s rev 02 127
- Page 127 of 177 127
- Tab 7 f 127
- Copyright hpl january 2021 p4115s rev 02 128
- Page 128 of 177 128
- Tab 7 g 128
- Tab 7 h 128
- Tab 7 i 128
- Copyright hpl january 2021 p4115s rev 02 129
- I setup 129
- Page 129 of 177 129
- Copyright hpl january 2021 p4115s rev 02 130
- Page 130 of 177 130
- Tab 7 j 130
- Alarm table 131
- Copyright hpl january 2021 p4115s rev 02 132
- Page 132 of 177 132
- Prack pr300t 0300018en rel 1 02 5 017 132
- I o table 133
- The list of prack pr300t inputs and outputs is reported below 133
- Copyright hpl january 2021 p4115s rev 02 134
- Line 2 134
- Page 134 of 177 134
- Copyright hpl january 2021 p4115s rev 02 135
- Page 135 of 177 135
- Prack pr300t 0300018en rel 1 02 5 017 135
- Copyright hpl january 2021 p4115s rev 02 136
- Line 2 136
- Page 136 of 177 136
- Copyright hpl january 2021 p4115s rev 02 137
- Page 137 of 177 137
- Prack pr300t 0300018en rel 1 02 5 017 137
- Analog inputs 138
- Copyright hpl january 2021 p4115s rev 02 138
- Line 2 138
- Page 138 of 177 138
- Alarm management 139
- Alarms 139
- Alarms cae01 139
- Alarms cae02 alarm 1 description 139
- Compressor alarms 139
- Generic overload high pressure low pressure oil 139
- Number of alarms for each compressor 3 139
- L1 alarms alc90 140
- L1 alarms alc92 140
- L1 generic alarm comp c01 c02 c03 140
- L1 high press al comp c01 c02 c03 140
- Pressure alarms from pressure switch 140
- Pressure and prevent alarms 140
- Heat reclaim or chillbooster 141
- High pressure prevention 141
- Hp by pressostat 141
- Hp by probe 141
- Offset 141
- Pressure 141
- Pressure alarms from probe 141
- Prevent 141
- Commissioning software 142
- Plantvisor pro and plantwatch pro supervisory systems 142
- Supervisory and commissioning systems 142
- Copyright hpl january 2021 p4115s rev 02 143
- Page 143 of 177 143
- Smart key operating instructions 143
- Software update and configuration 143
- Tab 10 a 143
- Tab 10 b 143
- Tab 10 c 143
- Tab 10 d 143
- Changing a parameter 144
- Commissioning 144
- Iinstalling the application to update the software 144
- Prack manager operating instructions 144
- Commissioning basic concepts 145
- File extensions names and contents 145
- Pendrive operating instructions 145
- Prack load basic concepts 145
- Support fi les 145
- Upload 146
- Usb key 146
- Automatic upload 147
- No link 147
- Upload in autorun mode 147
- Download 148
- Manual upload 148
- Confi guring pconet 149
- Confi guring pcoweb 149
- Confi guring pcoweb pconet from a system screen 149
- Connecting to a computer 149
- A system confi gurations with more than one plan board 150
- Appendix 150
- Agenzia agency 152
- Copyright hpl january 2021 p4115s rev 02 152
- Page 152 of 177 152
- B carel 10hp 153
- Abb inverter manual 159
- B abb non default settings 10hp 160
- 24v dgnd dcom di1 di2 164
- 24v dgnd dcom di1 di2 di3 di4 dio1 dio2 dio src dio com 164
- Acs380 drive quick installation and start up guide 164
- Ai1 agnd ai2 agnd ao agnd scr 10v 164
- Analog i o 164
- Analog input circuit common 164
- Analog output circuit common 164
- Aux 24 v dc 200 ma 164
- Aux 24 v dc max 200 ma 164
- Aux voltage output common 164
- B a bgnd shield termination 164
- C abb quick installation and start up guide 164
- Canopen profibus dp ethercat ethernet ip profinet modbus tcp canopen 164
- Connect the conductors to the correct control terminals torque the terminals to 0 n m 4 lbf in 164
- Connect the control cables 164
- Connect the pe conductor of the input power cable to the grounding terminal if it is necessary use a second pe conductor 164
- Connect the phase conductors of the input power cable to the l1 l2 and l3 input terminals torque the terminals to 0 n m 7 lbf in 164
- Connect the phase conductors of the motor cable to the t1 u t2 v and t3 w motor terminals torque the terminals to 0 n m 7 lbf in 164
- Connect the power cables 164
- Connect the shields of the twisted pairs and grounding wires to the scr terminal torque the terminals to 0 n m 4 lbf in 164
- Descriptions 164
- Digital i o connections 164
- Digital input common 164
- Digital input output common 164
- Digital output auxiliary voltage 164
- Dsub9 dsub9 rj45 x 2 rj45 x 2 rj45 x 2 rj45 x 2 164
- Eia 485 modbus rtu 164
- Embedded modbus rtu eia 485 164
- Examine the installation area 164
- Extension module connections 164
- Fault reset 164
- Forward 0 reverse 1 164
- Freq ref speed ref 0 0 v 164
- Ground the motor cable shield under the grounding clamp 164
- If it is applicable connect the brake resistor cable to the r and udc terminals torque the terminals to 0 n m 7 lbf in use a shielded cable and ground the shield under the grounding clamp 164
- If the input power cable has a shield twist it into a bundle mark it and connect it to the grounding terminal 164
- Install the drive 164
- Install the drive onto the mounting screws 164
- K451 fdna 01 devicenet terminal block 164
- K454 fpba 01 m profibus dp 164
- K457 fcan 01 m canopen 164
- K469 feca 01 m ethercat 164
- K470 fepl 02 ethernet power link rj45x2 164
- K475 fena 21 m ethernet ip profinet modbus tcp 164
- K495 bcan 11 canopen interface 164
- Make marks onto the surface for the mounting holes refer to declaration of conformity the r3 and r4 drives contain a mounting template 164
- Make sure that the drive is correctly installed 164
- Make sure that the motor cable is connected to the motor and disconnected from the drive output terminals t1 u t2 v and t3 w 164
- Make the holes for the mounting screws and install suitable plugs or anchors 164
- Measure the insulation resistance 164
- Mechanically attach the cables on the outside of the drive 164
- Mechanically attach the control cables on the outside of the drive 164
- Move the locking part to the left 164
- Move the locking part to the right 164
- No fault fault 1 164
- Not configured 164
- Output frequency 0 0 ma 164
- Process i o cyclic 164
- Push and hold the locking button down 164
- Put the drive against the bottom edge of the din installation rail 164
- Put the top tabs of the drive onto the top edge of the din installation rail 164
- Ramp 1 0 ramp 2 1 164
- Rc ra rb 164
- Ready 0 not ready 1 164
- Reference voltage 164
- Relay output 164
- Relay output 1 164
- Release the locking button 164
- S sgnd s1 s2 164
- Safe torque off function connected at factory drive starts only if both circuits are closed 164
- Safe torque off sto 164
- Select the cables 164
- Signal cable shield screen 164
- Speed selection 164
- Start to tighten the screws into the mounting holes 164
- Stop 0 start 1 164
- Strip a part of the outer shield of the control cable for grounding 164
- Strip the control cable conductors 164
- Strip the input power cable 164
- Strip the motor cable 164
- Terminals 164
- Tighten the mounting screws 164
- To remove the drive use a flat head screwdriver to open the locking part 164
- Twist the motor cable shield into a bundle mark it accordingly and connect it to the grounding terminal 164
- Use a cable tie to ground the outer shield to the grounding tab 164
- Use a voltage of 500 v dc to measure the insulation resistance between each phase conductor and the protective earth conductor the insulation resistance of an abb motor must be more than 100 mohm at 25 c 77 f for the insulation resistance 164
- Use metal cable ties for 360 degree grounding 164
- 10 50 c 14 22 f up to 60 c with derating except r0 no frost allowed 165
- Abb drives 165
- Acc dec time 1 165
- Acs380 04xx 165
- Act1 16 bit 165
- Air temperature 165
- Ambient conditions 165
- Axd10000299801 xls 165
- Canopen 165
- Canopen bcan 11 165
- Canopen fcan 01 m 165
- Ce marking 165
- Certifications 165
- Cia 402 165
- Class 3c2 165
- Class 3s2 165
- Configure fieldbus communications 165
- Constant frequency sel1 165
- Constant frequency sel2 165
- Constant speed sel1 165
- Constant speed sel2 165
- Contamination levels iec 60721 3 3 165
- Copyright hpl january 2021 p4115s rev 02 165
- Cross connection the input and motor cable connections are incorrect 165
- Cw 16 bit 165
- Dc link overvoltage there is an overvoltage in the intermediate dc circuit 165
- Dc link undervoltage there is an undervoltage in the intermediate dc circuit 165
- Declaration of conformity 165
- Depth 1 165
- Depth 2 165
- Description 165
- Dimensions and weights 165
- During operation installed for stationary use 165
- Eac marking 165
- Earth leakage a load unbalance that is typically caused by an earth fault in the motor or the motor cable 165
- Efb communication loss break in embedded fieldbus communication 165
- Efb ref1 165
- Eip abb pro 165
- Embedded fieldbus 165
- Enable 165
- Ethercat 165
- Ethernet ip 165
- Examine the direction of the motor if it is necessary set the motor direction with the phase order setting or with the phase order of the motor cable 165
- Ext1 commands 165
- Ext1 frequency ref1 165
- Ext1 in1 165
- Ext1 in2 165
- Ext1 speed ref1 165
- Fault reset selection 165
- Fb a ref1 165
- Fba a comm loss func 165
- Fba a communication communication lost between drive and fieldbus adapter 165
- Fba a data in1 165
- Fba a data in2 165
- Fba a data out1 165
- Fba a data out2 165
- Fba a enable 165
- Fieldbus a 165
- Fra me size 165
- Frame size 165
- Free fall 165
- Free space required 165
- Free space requirements 165
- Freq ramp set selection 165
- Heavy duty use 165
- Height back 165
- Height front 165
- Identification run the motor id run occurs at the next start 165
- Iec ratings 165
- If you need to change other parameters you can set them manually refer to the acs380 firmware manual 3axd50000029275 english and the applicable fieldbus adapter documentation 165
- In the control macros view select the applicable macro to configure fieldbus communications refer to configure fieldbus communications 165
- In the motor control view set the start and stop mode 165
- Input phase loss the intermediate dc circuit voltage oscillates 165
- Input rating 165
- Input with choke 165
- Installation altitude 165
- Ip configuration 165
- Light duty use 165
- Max current 165
- Mb tcp abb c 165
- Modbus tcp ip 165
- Mounting hole distance 1 165
- Mounting hole distance 2 165
- Nema ratings 165
- Node address 165
- Nominal use 165
- Not allowed 165
- Not selected 165
- Output phase loss all three phases are not connected to the motor 165
- Output ratings 165
- Overcurrent the output current is more than the internal limit this can be caused by an earth fault or phase loss 165
- Page 165 of 177 165
- Parameter 165
- Phase un 200 240 v 165
- Phase un 380 480 v 165
- Phase un 460 v 440 480 v 165
- Pnio abb pro 165
- Power up the drive 165
- Profibus 165
- Profile 165
- Profinet 165
- Protocol enable 165
- Protocol profile 165
- Ramp set selection 165
- Ratings 165
- Rcm marking 165
- Ref 1 16 bit 165
- Ref1 16 bit 165
- Related documents 165
- Relative humidity 165
- Requirement 165
- Safe torque off 1 the safe torque off circuit 1 is broken 165
- Safe torque off 2 the safe torque off circuit 2 is broken 165
- Safe torque off the safe torque off sto function is on 165
- Select the unit international or us in the motor data view set the motor type asynm asynchronous motor pmsm permanent magnet synchronous motor synmr synchronous reluctance motor 165
- Set the acceleration and deceleration times 165
- Set the maximum and minimum speeds 165
- Set the motor control mode vector speed reference this is suitable for most cases the drive does an automatic standstill id run when the drive is started for the first time scalar frequency reference do not use this mode for permanent magne 165
- Set the nominal motor values 165
- Setting 165
- Setting canopen with bcan 11 165
- Setting general 165
- Shock iec 60068 2 27 ista 1a 165
- Short circuit there is a short circuit in the motor or the motor cable 165
- Start up the drive 165
- Static ip 165
- Sw 16 bit 165
- Symbols 165
- The drive software recognizes the connected adapter i o modbus module or some of the fieldbus modules and selects the correct settings for fieldbus communication refer also to configure fieldbus communications 165
- The drive software recognizes the connected fieldbus adapter and selects the correct fieldbus control macro 165
- Tune the drive parameters to the application you can use the assistant control panel acs ap x or the drivecomposer pc tool refer to the acs380 firmware manual 3axd50000029275 english 165
- Tüv nord marking 165
- Ul marking 165
- Up to 95 without condensation 165
- V units 0 000 m above sea level with derating above 1000 m 400 v units 0 000 m above sea level with derating above 1000 m 1 165
- Warning 165
- Warning current calibration is done at the next start fault output phase current measurement fault 165
- Warnings and faults generated by the drive 165
- Weight 165
- You can see the selected fieldbus control macro in the control macros view or from parameter 96 5 in the control macros view you can also change some adapter specific settings 165
- Pressure and enthalpy diagram 166
- Ph 10hp 167
- R744 co2 p h diagram subcritical 168
- R744 co2 p h diagram transcritical 169
- Commissionimg form 170
- Co2 hermetic rotary commissioning form 171
- Co2 hermetic rotary condending unit 171
- Commissioning form 171
- Sheet1 171
- Directive 2009 125 ec 173
- Eco design 173
- Ecodesign 173
- Evaporator installation guide 174
Похожие устройства
- Daikin GCU2040PXB1 Брошюра
- Daikin GCU2040PXB1 Инструкция по монтажу
- Daikin HCU2040PXB1 Технические данные
- Daikin HCU2040PXB1 Инструкция по монтажу
- Daikin HCU4070PXB1 Технические данные
- Daikin HCU4070PXB1 Инструкция по монтажу
- Daikin LRYEN10A7Y1 Общие правила техники безопасности
- Daikin LRYEN10A7Y1 Инструкция по эксплуатации
- Daikin LRYEN10A7Y1 Справочное руководство для монтажника
- Daikin LRYEQ16A7Y1 Инструкция по эксплуатации
- Daikin LRYEQ16A7Y1 Брошюра
- Daikin LRLEQ3BY1 Технические данные
- Daikin LRLEQ3BY1 Общие правила техники безопасности
- Daikin LRLEQ3BY1 Инструкция по эксплуатации
- Daikin LRLEQ3BY1 Руководство по применению для установщика
- Daikin LRLEQ4BY1 Технические данные
- Daikin LRLEQ4BY1 Общие правила техники безопасности
- Daikin LRLEQ4BY1 Инструкция по эксплуатации
- Daikin LRLEQ4BY1 Руководство по применению для установщика
- Daikin LRLEQ5AY1 Справочное руководство для монтажника
