pRack PR300T +0300018EN rel. 1.5 - 02.05.2017
Mask index Display description Description Def. U. of M.Values
Caf04 Refrigerant type Type of refrigerant (suction line 1) R744 --- R22 | R134a
R404A | R407C
R410A | R507A
R290 | R600
R600a | R717
R744 | R728
R1270 | R417A
R422D | R413A
R422A | R423A
R407A | R427A
R245Fa | R407F | R32
Caf05 Min.time on Minimum compressor on time (line 1) 30 s 0…999
Min.time o Minimum compressor o time (line 1) 120 s 0…999
Minimum time to start same
comp.
Minimum time between starts of same compressor (line 1) 360 s 0…999
Caf06 Startup Type of compressor startup direct --- Direct
Part winding
Star delta
Caf07 Star time Star relay run time 0 ms 0…9999
Star delay/line Delaty betwen star and line relay 0 ms 0…9999
Star delta delay Delay between star and delta relay 0 ms 0…9999
Caf08 Partwinding delay Partwinding delay 0 ms 0…9999
Caf09 Equalization Enable compressor equalization at startup NO --- NO | YES
Equal. time Equalization duration 0 s 0…999
Caf10 Device rotation type Type of rotation FIFO --- ---
FIFO
LIFO
TIME
CUSTOM
Caf11 Device sequence Unloader sequence in relation to compressor activation (C=compressor, P=unloader) CpppCppp --- ----
CCpppppp
CpppCppp
Caf12 Load up time Delay between di erent compressor starts 10 s 0…999
Shutdown time Delay between di erent compressor shutdowns 0 s 0…999
Unloader delay Delay between stages 0 s 0…999
Caf13 Custom rotation on order Order of startup for compressor custom rotation 1 --- 1…16
Caf14 Custom rotation o Order of shutdown for compressor custom rotation 1 --- 1…16
Caf15 Modulation device Compressor modulating device type (line 1) None --- None
Inverter
Digital scroll
Caf16 Min frequency Minimum inverter frequency 30 Hz 0…150
Max frequency Maximum inverter frequency 60 Hz 0…150
Caf17 Min.time on Minimum time compressor controlled by inverter on (line 1) 30 s 0…999
Min.time o Minimum time compressor controlled by inverter o (line 1) 60 s 0…999
Minimum time to start same
comp.
Minimum time compressor controlled by inverter startup (line 1) 180 s 0…999
Caf18 Digital comp. valve
regulation
Digital Scroll™ compressor valve control type (line 1) Optimized
regulation
--- Optimized regulat.
Variable cycle time
Fixed cycle time
Cycle time Cycle time (line 1) 13 s 12…20
Caf19 Oil dilution Enable Digital Scroll™ oil temperature alarm (line 1) enable --- disable | enable
Discharge temp Enable Digital Scroll™ discharge temperature alarm (line 1) enable --- disable | enable
…… … ………
Caf90 Di erent sizes Enable compressors of di erent sizes (line 1) NO --- NO | YES
Di erent number of valves Enable compressor partialization (line 1) NO --- NO | YES
Caf91 S1 Enable size and size for compressor group 1 (line 1) YES'
10.0
---
kW
NO | YES
0.0…500.0
…… ………
S4 Enable size and size for compressor group 4 (line 1) NO ---
---
kW
---
NO | YES
0.0…500.0
Caf92 S1 Enable stages and stages for compressor group 1 (line 1) YES'
100
---
%
NO | YES
100 | 50 | 100 | 50
75 | 100 | 25 | 50
75 | 100 | 33 | 66|100
…… ………
S4 Enable stages and stages for compressor group 4 (line 1) NO
---
---
kW
NO | YES
S1…S4
Caf93 C01 Size group for compressor 1 (line 1) or presence of inverter (line 1) S1 --- S1…S4 | INV
…… ………
C12 Size group for compressor 6 (line 1) S1 --- S1…S4
Caf95 Min.time on Minimum time on for Digital Scroll
TM
compressor (line 1) 60 s 0…999
Min.time o Minimum time o for Digital Scroll
TM
compressor (line 1) 180 s 0…999
Minimum time to start
same comp.
Minimum time between startups for Digital Scroll
TM
compressor (line 1) 360 s 0…999
Reactivate startup procedure
after
Time for reactivation of startup procedure for Digital Scroll
TM
compressor (line 1) 480 min 0…9999
Cag01 Minimum voltage Voltage corresponding to the minimum capacity of the inverter (line 1) 0.0 V 0.0…10.0
Maximum voltage Voltage corresponding to the maximum capacity of the inverter (line 1) 10.0 V 0.0…10.0
Nominal freq. Nominal frequency (frequency at nominal capacity) (line 1) 50 Hz 0…150
Nominal power Nominal capacity for compressor managed by inverter at nominal frequency (line 1) 10.0 kW 0.0…500.0
Cag02 Rising time Time to pass from minimum to maximum capacity for modulating device (line 1) 90 s 0…600
Falling time Time to pass from maximum to minimum capacity for modulating device (line 1) 30 s 0…600
Cag03 Enable compressor modulat.
in dead zone
Enable compressor 1 modulation inside dead zone (line 1) AB --- Disabled
abled
Cag04 Enable suction press.backup
probe
Enable screens for the con guration of the suction pressure backup probe (line 1) NO --- NO | YES
Cag05 Request in case of regulation
probe fault
Compressor forcing value in case of suction probe fault (line 1) 50.0 % 0.0…100.0
Pumpdown Enable pumpdown function (line 1) Disabled --- disabled
abled
Threshold Pumpdown end threshold (line 1) 1.5 barg … … (**)
Cag06 Enable anti return of liquid Enable liquid non return function (line 1) NO --- NO | YES
Delay Delay liquid non return function (line 1) 0 min 0…15
