81
ENG
pRack PR300T +0300018EN rel. 1.5 - 02.05.2017
Mask index Description Channel Logic Notes
Suction
Bacan, Cba80
Line relay compressor 7 line 2
Partwinding/ Star relay compressor 7 line 2
Delta relay compressor 7 line 2
Bacao, Cba81 Valve 1, compressor 7 line 2
Bacap, Cba82 Valve 2, compressor 7 line 2
Bacar, Cba83 Equalization valve compressor 7 line 2
Bacas Cba86
Line relay compressor 8 line 2
Partwinding/ Star relay compressor 8 line 2
Delta relay compressor 8 line 2
Bacat, Cba87 Valve 1, compressor 8 line 2
Bacau, Cba88 Valve 2, compressor 8 line 2
Bacaw, Cba89 Equalization valve compressor 8 line 2
Bacax, Cba92
Line relay compressor 9 line 2
Partwinding/ Star relay compressor 9 line 2
Delta relay compressor 9 line 2
Bacay, Cba93 Valve 1, compressor 9 line 2
Bacbb, Cba94 Equalization valve compressor 9 line 2
Bacbc, Cba96
Line relay compressor 10 line 2
Partwinding/ Star relay compressor 10 line 2
Delta relay compressor 12 line 2
Bacbd, Cba97 Valve 1, compressor 10 line 2
Bacbg, Cba98 Equalization valve compressor 10 line 2
Bacbh, Cbaaa
Line relay compressor 11 line 2
Partwinding/ Star relay compressor 11 line 2
Delta relay compressor 11 line 2
Bacbi, Cbaab Valve 1, compressor 11 line 2
Bacbl, Cbaac Equalization valve compressor 11 line 2
Bacbm, Cbaae
Line relay compressor 12 line 2
Partwinding/ Star relay compressor 12 line 2
Delta relay compressor 12 line 2
Bacbn, Cbaaf Valve 1, compressor 12 line 2
Bacbq, Cbaag Equalization valve compressor 12 line 2
Condenser
Baccn, Dba20 Fan 1 line 2
Bacco, Dba21 Fan 2 line 2
Baccp, Dba22 Fan 3 line 2
Baccq, Dba23 Fan 4 line 2
Baccr, Dba24 Fan 5 line 2
Baccs, Dba25 Fan 6 line 2
Bacct, Dba26 Fan 7 line 2
Baccu, Dba27 Fan 8 line 2
Baccv, Dba28 Fan 9 line 2
Baccw, Dba29 Fan 10 line 2
Baccx, Dba30 Fan 11 line 2
Baccy, Dba31 Fan 12 line 2
Baccz, Dba32 Fan 13 line 2
Bacda, Dba33 Fan 14 line 2
Bacdb, Dba34 Fan 15 line 2
Bacdc, Dba35 Fan 16 line 2
Bacdd, Dba36 Fan inverter warning, line 1
Other functions
Bacde, Eeba03 Heat recovery pump, line 2
Bacdf, Egba02 ChillBooster line 2
Bacds, Eaba10 Oil pump 1 line 2
Bacdt, Eaba11 Oil pump 2 line 2
Bacdu, Eaba12 Oil fan line 2
Baceb, Ecba07, Edba07 Liquid injection valve compressor 1 line 2
Bacec, Ebca08, Edba08 Liquid injection valve compressor 2 line 2
Baced, Ecba09, Edba09 Liquid injection valve compressor 3 line 2
Bacee, Ecba10, Edba10 Liquid injection valve compressor 4 line 2
Bacef, Ecba11, Edba11 Liquid injection valve compressor 5 line 2
Baceg, Ecba12, Edba12 Liquid injection valve compressor 6 line 2
Bac72 Non return of liquid, line 2
Bacep Forcing from BMS, line 2
Bacel, Ebbb01 Subcooling, line 2
Eaba23 Common oil level valve line 2
Eaba40 Oil level valve compressor 1 line 2
Eaba41 Oil level valve compressor 2 line 2
Eaba42 Oil level valve compressor 3 line 2
Eaba43 Oil level valve compressor 4 line 2
Eaba44 Oil level valve compressor 5 line 2
Eaba45 Oil level valve compressor 6 line 2
Ebaa01 Subcooling valve line 2
Baceo Oil receiver line 2
Bacdg, Efe21 Stage 1 generic function
Bacdh, Efe22 Stage 2 generic function
Bacdi, Efe23 Stage 3 generic function
Bacdj, Efe24 Stage 4 generic function
Bacdk, Efe25 Stage 5 generic function
Bacdl Alarms present
Bacdm, Efe26 Generic alarm function 1
Bacdn, Efe27 Generic alarm function 2
Bacdo, Efe28 General scheduling function
Page 130 of 169
Copyright HPL March 2021
P4367 Rev 01
