pRack PR300T +0300018EN rel. 1.5 - 02.05.2017
Mask index Description Channel Logic Notes
Suction
Bac66, Caaae
Line relay compressor 12 line 1
Partwinding/ Star relay compressor 12 line 1
Delta relay compressor 12 line 1
Bac67, Caaaf Valve 1, compressor 12 line 1
Bac70, Caaag Equalization valve compressor 12 line 1
Condenser
Bacbt, Daa21 Fan 1 line 1
Bacbu, Daa22 Fan 2 line 1
Bacbv, Daa23 Fan 3 line 1
Bacbw, Daa24 Fan 4 line 1
Bacbx, Daa25 Fan 5 line 1
Bacby, Daa26 Fan 6 line 1
Bacbz, Daa27 Fan 7 line 1
Bacca, Daa28 Fan 8 line 1
Baccb, Daa29 Fan 9 line 1
Baccc, Daa30 Fan 10 line 1
Baccd, Daa31 Fan 11 line 1
Bacce, Daa32 Fan 12 line 1
Baccf, Daa33 Fan 13 line 1
Baccg, Daa34 Fan 14 line 1
Bacch, Daa35 Fan 15 line 1
Bacci, Daa36 Fan 16 line 1
Other functions
Bacck, Eeaa03 Heat recovery pump, line 1
Baccl, Egaa02 ChillBooster line 1
Bacdp, Eaaa11 Oil pump 1 line 1
Bacdq, Eaaa12 Oil pump 2 line 1
Bacdr, Eaaa13 Oil fan 1 line 1
Bacdv, Ecaa07, Edaa07 Liquid injection valve / Economizer compressor 1 line 1
Bacdw, Ecaa08, Edaa08 Liquid injection valve / Economizer compressor 2 line 1
Bacdx, Ecaa09, Edaa09 Liquid injection valve / Economizer compressor 3 line 1
Bacdy, Ecaa10, Edaa10 Liquid injection valve / Economizer compressor 4 line 1
Bacdz, Ecaa11, Edaa11 Liquid injection valve / Economizer compressor 5 line 1
Bacea, Ecaa12, Edaa12 Liquid injection valve / Economizer compressor 6 line 1
Bacei Forcing from BMS, line 1
Bacej Non return of liquid, line 1
Bacek, Ebaa01 Subcooling, line 1
Eaaa40 Oil level valve compressor 1 line 1
Eaaa41 Oil level valve compressor 2 line 1
Eaaa42 Oil level valve compressor 3 line 1
Eaaa43 Oil level valve compressor 4 line 1
Eaaa44 Oil level valve compressor 5 line 1
Eaaa45 Oil level valve compressor 6 line 1
Bac71 Oil receiver line 1
Eaaa16 Oil cooling compressor 1 line 1
Eaaa19 Oil cooling compressor 2 line 1
Eaaa22 Oil cooling compressor 3 line 1
Eaaa25 Oil cooling compressor 4 line 1
Eaaa28 Oil cooling compressor 5 line 1
Eaaa31 Oil cooling compressor 6 line 1
Eaaa54 Common oil level valve line 2
Ebaa01 Subcooling valve (line 1)
Baceh Sign of life
Bacem Normal alarm
Bacen Serious alarm
Line 2
Mask index Description Channel Logic Notes
Suction
Bac73, Cba08
Line relay compressor 1 line 2
Partwinding/ Star relay compressor 1 line 2
Delta relay compressor 1 line 2
Bac74, Cba09 Valve 1, compressor 1 line 2
Bac75, Cba10 Valve 2, compressor 1 line 2
Bac76, Cba11 Valve 3, compressor 1 line 2
Bac78, Cba12 Equalization valve compressor 1 line 2
Bac79, Cba22
Line relay compressor 2 line 2
Partwinding/ Star relay compressor 2 line 2
Delta relay compressor 2 line 2
Bac80, Cba23 Valve 1, compressor 2 line 2
Bac81, Cba24 Valve 2, compressor 1 line 2
Bac82, Cba25 Valve 3, compressor 1 line 2
Bac84, Cba26 Equalization valve compressor 1 line 2
Bac86, Cba35
Line relay compressor 3 line 2
Partwinding/ Star relay compressor 3 line 2
Delta relay compressor 3 line 2
Bac87, Cba36 Valve 1, compressor 3 line 2
Bac88, Cba37 Valve 2, compressor 3 line 2
Bac89, Cba38 Valve 3, compressor 3 line 2
Bac91, Cba39 Equalization valve compressor 3 line 2
Bac92, Cba47
Line relay compressor 4 line 2
Partwinding/ Star relay compressor 4 line 2
Delta relay compressor 4 line 2
Bac94, Cba48 Valve 1, compressor 4 line 2
Bac95, Cba49 Valve 2, compressor 4 line 2
Bac96, Cba50 Valve 3, compressor 4 line 2
Bac98, Cba51 Equalization valve compressor 4 line 2
Bacaa, Cba60
Line relay compressor 5 line 2
Partwinding/ Star relay compressor 5 line 2
Delta relay compressor 5 line 2
Bacab, Cba61 Valve 1, compressor 5 line 2
Bacac, Cba62 Valve 2, compressor 5 line 2
Bacad, Cba63 Valve 3, compressor 5 line 2
Bacaf, Cba64 Equalization valve compressor 5 line 2
Bacag, Cba72
Line relay compressor 6 line 2
Partwinding/ Star relay compressor 6 line 2
Delta relay compressor 6 line 2
Bacah, Cba73 Valve 1, compressor 6 line 2
Bacai, Cba74 Valve 2, compressor 6 line 2
Bacaj, Cba75 Valve 3, compressor 6 line 2
Bacal, Cba76
Equalization valve compressor 6 line 2
