19 Technical data
Installation and operation manual
41
LRYEN10A7Y1+LRNUN5A7Y1
CO₂ Conveni-Pack outdoor unit and capacity up unit
4P605461-1B – 2020.08
19.2 Piping diagram: Capacity up unit
15.9 C1220T-H
15.9 C1220T-H
L
RV
M
M
HPS
os
H
Pressure sensor Plate heat exchanger
HPS
Pressure switch Heat exchanger
Check valve
os
Oil separator
Service port
RV
Liquid receiver
Electronic expansion valve Distributor
Filter Refrigerant pipe
M
Propeller fan Oil and injection pipe
Compressor with accumulator
