19 Technical data
Installation and operation manual
43
LRYEN10A7Y1+LRNUN5A7Y1
CO₂ Conveni-Pack outdoor unit and capacity up unit
4P605461-1B – 2020.08
Capacity up unit
Notes:
1 This wiring diagram applies only to the capacity up unit.
2 Field wiring
3 Terminal block
Connector
Terminal
Protective earth (screw)
4 S1S is factory set to OFF. Set to ON or REMOTE to operate.
5 Use a voltage-free contact for microcurrent (≤1mA,
12VDC). For more information about the remote switches,
see details in "14.7.1Low voltage wiring – Capacity up
unit"[430].
6 Output (caution, warning, run, operation) is 220-240VAC,
with a maximum load of 0.5A.
7 For more information about the BS1~BS3 push buttons and
the DS1+DS2 DIP switches, see "16.1Making field
settings"[433].
8 Colours:
BLK Black
RED Red
BLU Blue
WHT White
GRN Green
YLW Yellow
Legend:
A1P Printed circuit board (main)
A2P Printed circuit board (M1C)
A3P Printed circuit board (noise filter) (M1C)
A4P Printed circuit board (M1F)
A5P Printed circuit board (ABC I/P 1)
A6P Printed circuit board (sub)
BS1~BS3 Push buttons (mode, set, return)
C503, C506 Capacitor (A2P)
C507 Film capacitor (A2P)
DS1, DS2 DIP switch (A1P)
E1HC Crankcase heater (M1C)
F1U, F2U Fuse (T 6.3A 250V) (A1P)
F1U Fuse (A6P)
F101U Fuse (A4P)
F3U, F4U Fuse (B 1A 250V)
F401U, F403U Fuse (A3P)
F601U Fuse (A2P)
HAP Light-emitting diode (service monitor is
green) (A1P, A2P, A4P, A6P)
K1R, K2R, K9R~K12R Magnetic relay (A1P)
K3R Magnetic relay (A2P)
L1R Reactor (A2P)
M1C Motor (compressor) (INV1)
M1F Motor (fan) (FAN1)
PS Switching power supply (A1P, A2P, A6P)
Q1LD Earth leakage detector (A1P)
R300 Resistor (A2P)
R10 Resistor (current sensor) (A4P)
R1T Thermistor (air) (A1P)
R2T Thermistor (M1C suction)
R3T Thermistor (M1C discharge)
R4T Thermistor (de-icer)
R5T Thermistor (liquid separator outlet)
R6T Thermistor (plate heat exchanger outlet)
R7T Thermistor (liquid pipe)
R9T Thermistor (M1C body)
S1NPH High pressure sensor
S1NPL Low pressure sensor (air conditioner)
S1NPM Medium pressure sensor
S1PH Pressure switch (high pressure protection)
(M1C)
S1S Operation switch (REMOTE/OFF/ON)
T1A Current sensor (A1P)
V1R Power module (A2P, A4P)
V1D Diode (A2P)
X1A, X2A Connector (M1F)
X3A Connector (A1P: X31A)
X4A Connector (A1P: X32A)
X5A Connector (A6P: X31A)
X1M Terminal block (power supply)
X2M Terminal block
X3M Terminal block (remote switch)
X4M Terminal block (compressor)
Y1E Electronic expansion valve
Y2E Electronic expansion valve
Y3E Electronic expansion valve
Y4E Electronic expansion valve
Z1C~Z11C Ferrite core
ZF Noise filter (with surge absorber) (A3P)
