INSTALL WASHING MACHINE

■ Unpacking the washing machine

Unpack your washing machine and check for transport damage. Check that all accessories are sup-

plied (as shown on page 4). In case of transport damage or missing accessories please contact your

local distributor directly.

■ Remove transport bolts

Before using this washing machine, transport bolts must be removed from the

backside of this machine. Please take the following steps to remove the bolts:

1. Loosen all bolts with spanner and then remove them.

2. Insert the supplied stoppers.

3. Keep the transport bolts properly for future use.

■ Select the location

Before installing the washing machine, the location characterized as follows shall be selected:

- Rigid, dry, and level surface (if not level, please make it level with reference to the following figure

Important:

Make sure that the washing machine will not stand on power cord.

Do not install the washing machine on the carpet floor.

If the machine nevertheless will be install on a carpet floor pls. take care that the floor staples do not

close or block the ventilation slots at the bottom of the machine.

On wood floor as you can see on old buildings please put a 22 mm wood plate or a 4 mm steel plate

under the machine because the washing machine will becomes in swinging spinning. If the washing

machine is standing on a plinth please make sure, that you will protect the washing machine accord-

in

2. After positioning the washing machine, press four corners on top cover of

washing machine in sequence. If the washing machine is not stable

when being pressed, this leg shall be adjusted.

3. Ensure the positioning status of washing machine. Loosen the lock nut

with spanner and turn the leg with hand until it closely contacts with the

floor. Press the leg with one hand and fasten the nut closely to the cabinet with the other hand.

4. Now check stability. Repeat steps 2 and 3 if necessary.

Please note: Generally only one foot has to be adjusted. In case the problem is at the rear you can

also adjust the diagonal front foot for the same effect.

is necessary to install a thin cover instead of the top cover (working plate).

This cover is available through the customer service or your distributor.

■ Co

nnect the inlet hose

Connect the inlet hose as shown in the figure.
