Use the new included inlet hose to connect the machine at the water supply.

Old hoses may not to use again.

Install the inlet hose

1. Connect the elbow fitting to the water tap and turn clockwise to tighten.

2. Connect the other end of the inlet hose to the inlet valve at the rear of the

washing machine and turn clockwise to tighten.

Please note:

If a leak develops remove the inlet hose and reconnect.

Connect to a standard water tap.

■ Place outlet hose

There are two ways to place the end of outlet hose:

1. Hang into a sink or trough.

2. Connect it to the branch drain pipe of the trough.

It can drain the water up and down, outlet hose shall not be installed at a height beyond 100 cm and

its end shall not be immersed in water

Electrical connection

- Maximum power input is 10 A when heating.

Please ensure that the wall outlet is accordingly equipped.

- Only connect the washing machine to an earthed wall outlet.

- Make sure the power voltage at your place is same to that in the machine's rating label.

- The plug must perfectly fit into the wall outlet.

- Do not use multi-purpose plug or socket as extension cord.

- Do not connect and pull out plug with wet hand.

- When connecting and pulling out the plug, hold the plug tightly and then pull it out. Do not pull

power cord forcibly.

- If power cord is damaged or has any sign of being broken, special power cord must be selected

or purchased from its manufacturer or service center for replacement.

CAUTION

Please observe the following to reduce the risk of fire, electric shock and other accidents:

- Only connect the washing machine to a power supply as specified on the rating label. Ask

your power provider if in doubt.

Min inlet water pressure 0

,05 MPa

Max inlet water pressure 1,0 MPa
