COMPACT CASSETTE
CONSTANT SPEED
Specifications
Model : AUG12ABAB / AUG18ABAB
AUG12RBAB / AUG18RBAB
Auto air flow direction and auto swing
Comfortable air flow
4-way
3-way2-way
Select 2-way, 3-way or 4-way air flow to suit your needs.
4
3
2
1
1
2
3
4
4 step swing 2-4 way air flow system
Steps
Auto swing
Wireless R.C.
Capacity
EER
COP
Running Current
Moisture Removal
Airflow Rate (High)
Sound Pressure
Net Dimension H
x
W
x
D
Net Weight
Piping Connections (Small / Large)
Max Height Difference
Operation Range
Cooling
Heating
Drain Pipe Diameter (I.D./O.D.)
Max Pipe Length (Pre-Charge)
Refrigerant
Cassette Grille
Heating
Cooling/HeatingInput Power
Power Source
Cooling
Cooling
Indoor
Outdoor
Indoor (High)
Outdoor
Heating
Cooling/Heating
Indoor / Grille
Outdoor
°CDB
mm
m
kg(lbs)
mm
kW
kg(lbs)
A
W/W
m
3
/h
I/h
dB(A)
mm
V/ Ø/Hz
kW
BTU/h
kW
BTU/h
Model No.
Indoor unit
Outdoor unit
AUG18ABAB
AOG18ANCKL
220-240/1/50
4.95-5.10
16,900-17,400
—
—
1.80-1.90 / —
2.75-2.68
—
8.50-8.00 / —
2.1
44
52
650
3,500
235x580x580/35x650x650
18.0(40)/2.2(5)
650x830x320
51.0 (112)
6.35/12.70
25.0/32.0
20(7.5)
8
10 to 43
—
R22
UTG-UDGD-W
AUG18RBAB
AOG18RNCKL
220-240/1/50
4.85-5.00
16,600-17,100
5.30-5.45
18,100-18,600
1.75-1.85 / 1.85-1.95
2.77-2.70
2.86-2.79
8.5-8.0 / 9.0-8.5
2.1
44
52
650
3,500
235x580x580/35x650x650
18.0(40)/2.2(5)
650x830x320
56.0 (123)
6.35/12.70
25.0/32.0
20(10)
8
10 to 43
-5 to 24
R22
UTG-UDGD-W
AUG12ABAB
AOG12AMAJL
220-240/1/50
3.65-3.70
12,400-12,600
—
—
1.36-1.44 / —
2.68-2.57
—
6.30-6.50 / —
1.6
42
49
550
1,600
235x580x580/35x650x650
18.0(40)/2.2(5)
530x750x250
32.0 (70)
6.35/12.70
25.0/32.0
20(7.5)
8
21 to 43
—
R22
UTG-UDGD-W
AUG12RBAB
AOG12RMAJL
220-240/1/50
3.55-3.60
12,100-12,300
4.00-4.10
13,700-14,000
1.26-1.34 / —
2.82-2.69
3.33-3.20
5.90-6.10 / 5.70-5.80
1.6
42
49
550
1,600
235x580x580/35x650x650
18.0(40)/2.2(5)
530x750x250
37(81)
6.35/12.70
25.0/32.0
20(10)
8
10 to 43
-5 to 24
R22
UTG-UDGD-W
093
SPLIT / CONSTANT SPEED
Optional parts
Additional Grille: UTG-AGDA-W
Compact grille fits European ceiling panel
(650 x 650 mm)
Compact size
235
400
580
Condensate pump lift to 400mm
Punch Hall grille
650
650
(unit: mm)
Fresh air can be introduced
through this opening
Conditioned air can be distributed by means of a distribution duct
1-way
2-way
Duct connection hole opening
Distribution
duct
Distribution
duct
Fresh air
Additional grille (optional parts)
770mm
770mm
Additional grille
The ceiling hole
Indoor Unit (grille)
650mm
650mm
Dimensions (Unit : mm)
20
35
66
235
650
245
580
650
580
440
(Hanging bolt position)
606
(Hanging bolt position)
400
(Grille measurement)
650
440
131
245
54
111
47
66
46
60
86
Dr
ain pipe(I.D 32)
.
600
(Ceiling opening measurement)
Side view
Top view
Bottom view
Bottom view (Panel)
Models: AUG12ABAB / AUG18ABAB / AUG12RBAB / AUG18RBAB
